Horizon - BQ-280
Technical Specifications
| Year | 2014 |
| Machine Condition | In Stock |
Machine Description
- one clamp perfect binder BQ-280.
- NO PRE MELTER.
.
Horizon BQ-280PUR.
one-clamp perfect binder.
.
- clamps: 1.
- spine gluing: PUR.
- sight gluing: hotmelt.
- book block thickness: integrated monitoring station (outside the clamp).
.
- milling section: with extraction.
- milling depth: adjustable.
- cover feeder: suction drum feeder with 4x scoring.
.
- technology: touch & work.
- saveable jobs: 200 memories for repeat orders.
.
.
- sheet size:.
max: 385 x 320 mm; min: 135 x 105 mm.
.
.
- cover size:.
max. 660 x 385mm; min. 240 x 135mm.
.
- book thickness: max. 50mm; min. 1mm.
.
- cover weight range: 90 - 300 g/sqm.
- cover pile hight: max. 70mm.
.
- speed: max. 500 cycles/h.
.
dimensions: 3.055 x 905 x 1.520mm.
- power: 400V/ 50Hz - 2,7kW.
-weight: 900kg...
The Horizon BQ-280 is a high-performance small perfect binder designed for efficient and precise bookbinding operations. As a one-clamp perfect binder, it specializes in producing professionally bound books, catalogs, manuals, and other printed materials with exceptional durability and quality. Featuring PUR spine gluing and hotmelt sight gluing, this machine ensures strong adhesion and flexibility, making it ideal for short to medium production runs. The BQ-280 incorporates advanced automation, including a touch-and-work interface, integrated monitoring station, and 200 saveable job memories for streamlined repeat orders. Its compact design, combined with robust construction and user-friendly technology, makes it a reliable choice for print shops, binderies, and in-plant production facilities seeking precision and efficiency in perfect binding applications.
Key Technical Aspects:
Dimensions and Specifications : The Horizon BQ-280 measures 3,055 x 905 x 1,520 mm (L x W x H) and weighs 900 kg. It operates on a 400V/50Hz power supply with a 2.7 kW power consumption. The machine achieves a maximum production speed of 500 cycles per hour and is designed for durability and precision in industrial environments.
Paper Handling : The BQ-280 accommodates book blocks with a maximum sheet size of 385 x 320 mm and a minimum of 135 x 105 mm. It supports book thicknesses ranging from 1 mm to 50 mm and handles cover weights between 90 - 300 g/sqm. The cover feeder features a suction drum with 4x scoring, ensuring accurate cover alignment and consistent binding quality. The milling section includes extraction for efficient debris removal, with adjustable milling depth for optimal spine preparation.
