Key Technical Aspects:

Dimensions and Specifications : The Heidelberg Cylinder KSBAZ has a total weight of approximately 5,500 kg and machine dimensions of 3.50 m (L) x 1.55 m (W) x 1.70 m (H). It operates with a power consumption ranging from 5.5 kW to 7 kW, making it a substantial yet efficient industrial printing solution.

Paper Handling : This machine accommodates a maximum paper size of 46 x 58.5 cm (18 x 23 inches) and a minimum paper size of 14 x 18 cm. It supports substrate thicknesses from 0.04 mm to 0.70 mm and features a high-pile delivery system for efficient output handling.

Printing Unit : The KSBAZ is a 2-color cylinder letterpress machine with a maximum printing size of 43.5 x 57 cm. It achieves a maximum speed of 5,000 sheets per hour and utilizes high-precision mechanical grippers for accurate multi-color registration.

Ink System : Equipped with two separate inking units, the machine features dual distribution and form rollers for consistent ink application. Inking control is managed via manual screw adjustment on both ink ducts, and manual washing devices are included for maintenance.

Plate Cylinder : The machine uses standard letterpress chases to lock two separate printing forms, ensuring secure and precise plate positioning for high-quality print results.
