Polar - 137 EM
Technical Specifications
| Year | 1992 |
| Machine Condition | In Stock |
Machine Description
Configuration: Programmable hydraulic paper cutter..
Year: 1992..
Cutting width: 137 cm..
Feeding depth: 137 cm..
Feeding height (pile height): 16.5 cm..
Clamp pressure: Minimum 150 daN / Maximum 4,500 daN..
Control system: EM model (Electronic Monitor) with digital display and programmable memory..
Safety features: Infrared light barriers and two-hand cut engagement..
Backgauge speed: 30 cm / second..
Smallest cut without false plate: 2.5 cm..
Smallest cut with false plate: 9.0 cm..
Table type: Chrome-surface air table (main and side tables)..
Knife speed: 45 cycles / minute..
Total weight: approximately 4,120 kg..
Machine dimensions (L x W x H): 2.85 m x 2.65 m x 1.71 m..
Power consumption: approximately 5.5 kW to 6.5 kW..
Power supply: 3-phase 380V/400V....
The Polar 137 EM is a programmable hydraulic paper cutter from the Guillotines category, designed for precise and efficient cutting of large paper stacks. Manufactured in 1992, this industrial-grade machine offers advanced features such as a digital control system, programmable memory, and robust safety mechanisms. With a cutting width of 137 cm and a high-speed backgauge, it ensures accuracy and productivity for high-volume cutting tasks. Ideal for print shops, packaging manufacturers, and commercial binderies, the Polar 137 EM delivers reliable performance, ease of operation, and consistent results for a wide range of cutting applications.
Key Technical Aspects:
Dimensions and Specifications : The Polar 137 EM has a cutting width of 137 cm and a feeding depth of 137 cm, with a maximum pile height of 16.5 cm. It operates with a clamp pressure ranging from 150 daN to 4,500 daN. The machine weighs approximately 4,120 kg and measures 2.85 m (L) x 2.65 m (W) x 1.71 m (H). It requires a 3-phase 380V/400V power supply with a consumption of 5.5 kW to 6.5 kW. The backgauge speed is 30 cm/second, and the knife achieves 45 cycles per minute.
Paper Handling : The machine features a chrome-surface air table (main and side tables) for smooth paper handling. It supports a minimum cut of 2.5 cm without a false plate and 9.0 cm with a false plate. Safety is ensured through infrared light barriers and a two-hand cut engagement system.
Polar - 137 EM
€ 9,000
Excluding taxes and shipping
