Nagel - Multinak

Key Technical Aspects:

Dimensions and Specifications :The Nagel Multinak has a length of approximately 7.5 meters, a width of 1.8 meters, and a height of 1.9 meters, with a total weight of around 12 tons. The machine's production capacity can reach up to 200 meters per minute, depending on the material and print quality requirements.

Paper Handling :The Nagel Multinak features a sophisticated paper handling system, including a unwind station with a maximum diameter of 1,000 mm and a rewind station with a maximum diameter of 1,200 mm. The machine can handle a wide range of materials, including paper, film, and foil, with a thickness range of 12-200 microns.

Printing Unit :The printing unit of the Nagel Multinak is equipped with up to 8 colors, using a combination of flexographic and gravure printing technologies. The machine's print speed can reach up to 200 meters per minute, with a maximum print width of 670 mm and a resolution of 1,200 dpi.

Ink System :The Nagel Multinak uses a high-quality, water-based ink system, with a maximum ink capacity of 20 liters per color. The machine features an automatic ink supply system, ensuring consistent ink flow and minimizing waste.

Plate Cylinder :The plate cylinder of the Nagel Multinak has a diameter of 1,067 mm and a repeat length range of 200-800 mm. The machine features a quick-change plate cylinder system, allowing for fast and efficient job changes and minimizing downtime.
