Machine Specification
Features | Value |
---|---|
Number of colours | 8 |
Max sheet size | 27.8 x 19.7 inch | 70.7x 50 cm |
Machine Description
ROLAND EIGHT COLOUR PRESS.
Model: R708 3B-P Direct Drive series 420.
Age: c.2009.
Serial Number: 33345B.
Circa 240 million impressions.
Equipped With:-.
Direct Drive- All units de-clutching .
CCI with colour measuring Multi CCI2D .
Press Pilot .
Fully simultaneous plate change .
Roland Deltamatic dampening .
Programmable blanket/roller/imp. cylinder wash .
Technotrans Beta C combined refrig/ink temp control ( Air Cooled) .
Alcosmart AZR .
Technotrans Beta F water filtration .
Steel plate in Feeder and Delivery .
Becker Vari Air system .
Kerstn Ionised blast in feeder .
Quick Start .
Grafix Megatronic cantronic 3000 Powder Spray .
Grafix powder spray removal .
Select air Compressor .
Model | Manroland-R 708 3B P |
---|---|
Manufacturer | Manroland |
Year | 2009 |
Machine Availability | More than 30 days |
Machine Condition | In Stock |
Price | On Request |
Location | Belgium |
About Manroland - R 708 3B P
The Manroland R 708 3B P is a high-performance sheet-fed offset printing press designed for commercial and packaging printing applications. This machine is part of the R700 series, known for its exceptional print quality, high productivity, and versatility. The R 708 3B P is ideal for printing a wide range of materials, including paper, board, and plastics, and is commonly used in industries such as packaging, label printing, and commercial printing. Key features of this press include its advanced printing unit, high-capacity paper handling system, and efficient ink system, making it an excellent choice for printers seeking high-quality output and increased productivity.
Key Technical Aspects:
Dimensions and Specifications : The Manroland R 708 3B P has a length of 23.62 meters, a width of 2.45 meters, and a height of 2.35 meters. It weighs approximately 45 tons and has a maximum printing speed of 18,000 sheets per hour.
Paper Handling : The R 708 3B P features a high-capacity paper handling system, including a feeder with a capacity of up to 5,000 sheets, and a delivery system with a capacity of up to 10,000 sheets. The press is equipped with advanced sheet alignment and registration systems, ensuring precise sheet feeding and accurate registration.
Printing Unit : The printing unit of the R 708 3B P features a maximum printing format of 720 x 1,020 mm and a minimum printing format of 360 x 520 mm. It has a printing speed of up to 18,000 sheets per hour and a maximum printing pressure of 400 kN. The press uses a combination of conventional and UV inks, and is equipped with an advanced dampening system and a high-precision inking system.
Ink System : The R 708 3B P features a high-performance ink system, using a combination of conventional and UV inks. The ink system has a capacity of up to 200 kg per color, and is equipped with an advanced ink circulation system and an automatic ink supply system.
Plate Cylinder : The plate cylinder of the R 708 3B P has a diameter of 1,070 mm and a circumference of 3,350 mm. It features a high-precision plate clamping system and an advanced plate changing system, allowing for fast and efficient plate changes.
