Manroland - R 706 3B P

Key Technical Aspects:

Dimensions and Specifications :The Manroland R 706 3B P has a maximum web width of 965 mm and a maximum printing speed of up to 80,000 copies per hour. The press weighs approximately 150 tons and has a total length of around 25 meters. The machine's capacity specifications include a maximum printing format of 570 x 890 mm and a minimum printing format of 350 x 500 mm.

Paper Handling :The paper handling system of the Manroland R 706 3B P features a splicer for automatic reel change, a infeed system with pneumatic web guiding, and a sheeter for cutting the printed web into individual sheets. The press has a maximum reel diameter of 1,200 mm and a maximum reel weight of 2,500 kg.

Printing Unit :The printing unit of the Manroland R 706 3B P is equipped with three printing couples, each consisting of a plate cylinder, a blanket cylinder, and an impression cylinder. The press has a maximum printing speed of 15 meters per second and a printing resolution of 60 lines per cm. The printing unit uses the offset printing technology, which provides high-quality prints with precise registration and color consistency.

Ink System :The ink system of the Manroland R 706 3B P uses a closed-loop ink circulation system, which ensures consistent ink viscosity and temperature. The press is equipped with a ink fountain with a capacity of 20 liters and an ink pump with a flow rate of 10 liters per minute. The ink system also features an automatic ink control system, which monitors and adjusts the ink flow to maintain optimal printing conditions.

Plate Cylinder :The plate cylinder of the Manroland R 706 3B P has a diameter of 1,067 mm and a width of 965 mm. The plate cylinder is designed for high-speed printing and is equipped with a automatic plate changing system, which allows for quick and easy plate changes. The plate cylinder is also equipped with a pneumatic clamping system, which ensures precise plate registration and secure clamping during printing.
