Mitsubishi - Diamond 3000S-5

Key Technical Aspects:

Dimensions and Specifications : The Mitsubishi Diamond 3000S-5 has a length of 7,480 mm, a width of 2,440 mm, and a height of 2,350 mm. It weighs approximately 12,000 kg and has a maximum sheet size of 720 x 1,020 mm. The press has a capacity of up to 15,000 sheets per hour.

Paper Handling : The Diamond 3000S-5 features a high-capacity feeder with a maximum pile height of 1,200 mm and a sheet size range of 360 x 520 mm to 720 x 1,020 mm. The press is equipped with a double-sheet detection system and an anti-marking system to prevent sheet-to-sheet marking. The delivery system has a maximum pile height of 1,500 mm and is equipped with a jogger and a pile-turning device.

Printing Unit : The Mitsubishi Diamond 3000S-5 has five printing units, each with a maximum printing speed of 15,000 sheets per hour. The press uses a three-cylinder arrangement with a diameter of 1,020 mm and a gearless drive system. The printing units are equipped with automatic plate changers and have a maximum plate size of 720 x 1,020 mm.

Ink System : The Diamond 3000S-5 uses a high-precision ink system with a maximum ink flow rate of 12 kg/h. The press is equipped with an ink temperature control system and an automatic ink supply system. The ink system features a chambered doctor blade system and a triple-roller inking system.

Plate Cylinder : The plate cylinder has a diameter of 1,020 mm and a length of 720 mm. It features a quick-change plate system and is equipped with a plate temperature control system. The plate cylinder is designed for high-precision plate registration and has a maximum plate thickness of 2.5 mm.
