Manroland - R 702 3B P

Key Technical Aspects:

Dimensions and Specifications : The Manroland R 702 3B P has a length of 12,500 mm, a width of 2,500 mm, and a height of 2,200 mm. It weighs approximately 25,000 kg and has a maximum sheet size of 720 x 1,020 mm. The press has a capacity of up to 15,000 sheets per hour.

Paper Handling : The R 702 3B P features a advanced paper handling system, including a suction tape feeder, a sheet alignment system, and a high-capacity delivery stacker. The press has a maximum pile height of 1,500 mm and can handle paper weights from 80 to 500 gsm.

Printing Unit : The printing unit of the R 702 3B P features a maximum printing speed of 15,000 sheets per hour, with a resolution of 300 lpi. The press uses a three-color offset printing process, with a maximum printing area of 720 x 1,020 mm. The printing unit is equipped with advanced features such as automatic plate changing, and a precision registration system.

Ink System : The R 702 3B P uses a high-performance ink system, with a maximum ink flow rate of 12 kg/h. The press is equipped with a ink fountain with a capacity of 20 kg, and features an advanced ink distribution system for consistent and precise ink transfer.

Plate Cylinder : The plate cylinder of the R 702 3B P has a diameter of 1,020 mm, and is designed for high-speed printing applications. The plate cylinder features a advanced clamping system, and is equipped with a precision registration system for accurate plate alignment.
