Komori - LS 29-5 CX H

Sheet Fed / Offset Komori LS 29-5 CX H
Sheet Fed / Offset Komori LS 29-5 CX H
Sheet Fed / Offset Komori LS 29-5 CX H
Sheet Fed / Offset Komori LS 29-5 CX H

Machine Specification

FeaturesValue
Number of colours5

Machine Description

PQC-S: touch console for ink, axial, circumferential diagonal + all wash-up remote control.
AMR (Automatic Make Ready): automatic preset for pressure, paper size and thickness setting.
PDC-SII : Spectral Print Density Control SII Model.
Suction belts on feeder.
Pneumatic side lays.
Feeler foot with ionizing antistatic blower.
Mechanic double sheet control.
Ultrasonic sensor double-sheet control.
Micrometric adjustment of the lateral pull pay by touch panel +/- 3 mm..
Optical fiber precision photocell system for front and side control + safety photocell for the sheet in advance.
AMR (Preset).
Ink, blanket and impression cylinders automatic washing devices.
Unhinging of the manual dosing roller only on the motor side.
Automatic machine lock through over-register sensor.
Mechanical compensator for the contact between the rollers.
Inkwell drum motorized.
Double diameter impression cylinders with anti-rust treatment.
Adjustment of the height of the strokes of the transfer gripper' bars.
FAPC fully automatic plate change.
Skeleton Transfer cylinders with Venturi system.
Komorimatic damping.
Varnishing unit with HARRIS & BRUNO chambered doctor blade system.
IR DRYER GRAFIX

ModelKomori-LS 29-5 CX H
ManufacturerKomori
Year2006
Machine AvailabilityImmediately from stock
Machine ConditionIn Stock
PriceOn Request
LocationItaly

About Komori - LS 29-5 CX H

The Komori LS 29-5 CX H is a high-performance sheet-fed offset printing press designed for commercial and packaging printing applications. This machine is part of the LS series, known for its exceptional print quality, high productivity, and reliability. The LS 29-5 CX H is equipped with advanced features such as Komori's proprietary KHS-AI (Advanced Intertech) inking system, which ensures consistent and precise ink transfer. This press is ideal for printing high-quality materials, including paper, board, and specialty substrates, and is commonly used in applications such as commercial printing, packaging, and label production.

Key Technical Aspects:

Dimensions and Specifications : The Komori LS 29-5 CX H has a maximum sheet size of 740 x 1040 mm (29.13 x 40.94 in) and a minimum sheet size of 360 x 520 mm (14.17 x 20.47 in). The machine weighs approximately 12,000 kg (26,455 lbs) and has a maximum printing speed of 18,000 sheets per hour.

Paper Handling : The LS 29-5 CX H features a high-capacity feeder with a maximum pile height of 1,500 mm (59 in) and a sheet capacity of 5,000 sheets. The press is equipped with a high-speed delivery system, which can handle up to 18,000 sheets per hour. The machine also features an optional automatic pile changer and a sheet ejection system.

Printing Unit : The printing unit of the LS 29-5 CX H features Komori's KHS-AI inking system, which ensures precise and consistent ink transfer. The machine has a maximum printing speed of 18,000 sheets per hour and a printing resolution of 300 lpi (lines per inch). The printing unit is equipped with five printing cylinders and five transfer cylinders.

Ink System : The LS 29-5 CX H uses a high-precision ink system with a maximum ink capacity of 20 kg (44 lbs) per color. The machine features an automatic ink supply system and an ink temperature control system, which ensures consistent ink viscosity and optimal printing performance.

Plate Cylinder : The plate cylinder of the LS 29-5 CX H has a diameter of 1,040 mm (40.94 in) and is designed for high-precision plate mounting. The machine features an automatic plate changing system, which allows for fast and efficient plate changes.
