Heidelberg - XL106-8P+LX4 18K

Sheet Fed / Offset Heidelberg XL106-8P+LX4 18K

Machine Specification

FeaturesValue
Number of colours8
Max sheet size41.7 x 29.5 inch | 106 x 75 cm

Machine Description

PRINECT PRESS CENTER touch screen consolle.
Press Center MasterLever.
Press Center DryStar Advanced.
Press Center IntantGate.
Press Center Color Assistant Pro.
PressCenter NetProfiler.
Prinect Inpress Control 2.
Press Center WallScren.
PRESET PLUS FEEDER : Suction belt feeder with 3 sections of transport of sheets to the frontal registers.
Double sheet detector - pulling device.
Non-stop on feeder.
StaticStar Compact: antistatic bar on feeder, two ionizator heads on feeder, four half ionizator bars in delivery.
HYCOLOR + VARIO SYSTEM damping.
Roller wash up device controlled by Prinect Press Center.
Blanket and impression cylinders automatic washing devices by Prinect Press Center.
Air Transfer System Venturi.
CombiStar pro inking unit temperature control, water cooled, with AlcoSmart.
Autoplate XL : simultaneous plate changer.
FilterStar: filtration System of the dampening solution.
CombiStar CANopen : Technotrans ink temp control combined with damping refrigeration + Alcosmart.
Coating Star CANopen : heat coater system.
Varnishing unit, with cooking register, Tresu chambered doctor blade system, with anilox roller.
Preset Plus Delivery : a lot of preset functions and memorization, aereodinamic grippers system, slow down system by Prinect, panel in delivery.
Extended Delivery X4.
DryStar 3000 Combination via CanOpen (5 slide-in dryers) : pos. 1 dryer slide-in unit IR/HA hot air; pos. 2 dryer slide-in unit HA hot air; pos. 3 dryer slide-in unit HA hot air; pos. 4 dryer slide-in unit HA hot air; pos. 5 dryer slide-in unit EX/CA col.
Weko PowderStar AP500 Duo.
CleanStar : powder suction device in delivery.
AirStar Pro : central air box water cooled.
SCROLLSTAR: Atlas Copco compressor.
Intercom system: Microphone communication.
18.000 speed/h

ModelHeidelberg-XL106-8P+LX4 18K
ManufacturerHeidelberg
Year2015
Machine AvailabilityImmediately from stock
Machine ConditionIn Stock
PriceOn Request
LocationItaly

About Heidelberg - XL106-8P+LX4 18K

The Heidelberg XL106-8P+LX4 18K is a high-performance, eight-color sheetfed offset printing press designed for commercial and packaging printing applications. This machine is part of the XL series, known for its exceptional print quality, high productivity, and versatility. The XL106-8P+LX4 18K is ideal for printing large-format materials, such as posters, point-of-purchase displays, and packaging materials, with its impressive maximum sheet size of 106 x 145 cm. Key benefits of this machine include its ability to handle a wide range of substrates, including paper, board, and plastics, as well as its advanced automation features that minimize makeready times and maximize production efficiency.

Key Technical Aspects:

Dimensions and Specifications : The Heidelberg XL106-8P+LX4 18K has a machine length of 23.5 meters, a machine width of 5.5 meters, and a machine height of 2.5 meters. It weighs approximately 45 tons and has a maximum sheet capacity of 18,000 sheets per hour.

Paper Handling : The XL106-8P+LX4 18K features a high-performance paper handling system, including a feeder with a capacity of up to 10,000 sheets, an infeed system with automatic sheet alignment, and a delivery system with a pile height of up to 2 meters. The machine is also equipped with an optional automatic pallet changer and a non-stop pile changer for uninterrupted production.

Printing Unit : The printing unit of the XL106-8P+LX4 18K features eight printing units, each with a maximum print speed of 18,000 sheets per hour. The machine uses Heidelberg's advanced Gapless Transfer Technology, which enables precise and consistent ink transfer, and its Preset Plus Feeder system, which ensures accurate sheet alignment and registration. The printing unit also features a maximum print resolution of 2,438 dpi.

Ink System : The XL106-8P+LX4 18K uses a high-performance ink system with a maximum ink flow rate of 1,200 kg/h. The machine features a dual-ink fountain system, which allows for the use of two different ink types, and an optional Anilox roller system for precise and consistent ink transfer.

Plate Cylinder : The plate cylinder of the XL106-8P+LX4 18K features a diameter of 1,060 mm and a circumference of 3,330 mm. The plate cylinder is designed for high-speed printing and features a maximum plate change time of 2 minutes. The machine also features an optional Autoplate XL2 plate changing system, which enables fully automatic plate changing and reduces makeready times.
