Machine Specification
| Features | Value |
|---|---|
| Number of colours | 6 |
| Max sheet size | 13.38 x 18.89 inch | 34 x 48 cm |
Machine Description
CP 2000 console touch screen, axial, circumferential and diagonal register remote control, ink ductors rotation control, job memorization.
CP 2000 MasterLevel.
Preset Plus Feeder.
Head feeder 3 more suctions for paper transport.
Ultrasonic sensor double-sheet control before front registers.
Front sensor on flap of the feeder.
Suction belt feeder with 3 sections of transport of sheets to the frontal registers.
Pneumatic side register control with integrated auto cleaning and double sheet control with direct system.
Slow down : system to slow the sheet down then 65% on feeder.
StaticStar Compact : No. 2 Eltex ion blowers on feeder, antistatic bars on feeder and delivery.
Ultrasonic double-sheet control.
Multiple-sheet detector/ tear-off.
Multiple sheet control/Forwarding roller.
Double sheet detector - pulling device.
Hycolor damping with VarioSystem.
Air transfer system.
Automatic roller wash-up device.
Automatic impressions and blanket cylinders wash-up device with cloths.
CombiStar CAN : Technotrans ink temp control combined with damping refrigeration + Alcosmart.
Varnishing unit, with cooking register, Tresu chambered doctor blade system, with anilox roller.
LWE roller storage coating unit facility.
Preset Plus Delivery : a lot of preset functions and memorization, aereodinamic grippers system, slow down system by CP 2000, panel in delivery.
PowderStar Weko AP 500 CANopen.
Non-Stop in delivery.
DryStar 3000 Combination 3 slide-in dryers, CanOpen : no. 1 dryer slide-in unit IR/HA air knives.
ScrollStar : Atlas Copco compressor.
AirStar Pro : central air box air cooled.
Intercom : Microphone communication system.
18.000 speed/h
| Model | Heidelberg-XL105-6 LX2 |
|---|---|
| Manufacturer | Heidelberg |
| Year | 2005 |
| Machine Availability | Immediately from stock |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Italy |
About Heidelberg - XL105-6 LX2
The Heidelberg XL105-6 LX2 is a high-performance sheet-fed offset printing press designed for commercial and industrial printing applications. This machine is part of the XL series, known for its exceptional print quality, high productivity, and versatility. The XL105-6 LX2 is ideal for printing a wide range of materials, including paper, board, and plastics, and is commonly used in applications such as packaging, label printing, and high-end commercial printing. Key features of this machine include its advanced printing unit, high-capacity paper handling system, and efficient ink system, making it an excellent choice for printers requiring high-volume production with precise color control.
Key Technical Aspects:
Dimensions and Specifications : The Heidelberg XL105-6 LX2 has a length of 23.62 ft (7.2 m), a width of 10.17 ft (3.1 m), and a height of 8.2 ft (2.5 m). It weighs approximately 44,000 lbs (20,000 kg) and has a maximum sheet size of 29.53 x 41.34 in (750 x 1050 mm).
Paper Handling : The XL105-6 LX2 features a high-capacity paper handling system, including a feeder with a capacity of up to 10,000 sheets, and a delivery system with a capacity of up to 12,000 sheets per hour. The machine is equipped with advanced sheet control and registration systems, ensuring precise sheet alignment and reduced waste.
Printing Unit : The printing unit of the XL105-6 LX2 is equipped with six printing units, each capable of producing up to 18,000 sheets per hour. The machine features a maximum print speed of 18,000 sheets per hour and a print resolution of 300 lpi (lines per inch). The printing unit utilizes Heidelberg's advanced Gapless Transfer Technology, ensuring precise color control and reduced waste.
Ink System : The XL105-6 LX2 features a high-performance ink system, utilizing Heidelberg's Saphira Eco ink series. The machine has a maximum ink capacity of 20 kg per color, and is equipped with an advanced ink metering system, ensuring precise ink control and reduced waste.
Plate Cylinder : The plate cylinder of the XL105-6 LX2 has a diameter of 6.3 in (160 mm) and is designed for high-speed printing applications. The plate cylinder features Heidelberg's advanced Plate Vice technology, ensuring precise plate registration and reduced waste.
