Machine Specification
| Features | Value |
|---|---|
| Number of colours | 5 |
| Max sheet size | 20.87X29.13 inch | 53x74 cm |
Machine Description
Impressions mil. c. 145.
CP2000: console for monitoring and control of the machine.
Steel plate on feeder.
Electronic control of double sheets.
Electronic control of the sheet missing.
Pointing tape sucked.
Photocells.
Automatic ink regulation from CP2000.
Ink temperature control.
Alcolor VARIO: dampening with speed compensation.
Refrigerator Technotrans.
Automatic Washing of blankets, rollers and impression cylinders.
Autoplate: semi-automatic plate change.
Preset: automatic paper size.
Automatic register with circumferential, axial and diagonal movement.
Automated perfecting device 2/3.
High pile delivery (H).
Powder spray Grafix Alphatronic 200.
Steel plate on delivery.
Speed 15.000 s/h.
CombiStar: inking unit temperature control Technotrans CAN and AlcolSmart, metering device of isopropyl alcohol (IPA)
| Model | Heidelberg-Speedmaster SM 74-5 P |
|---|---|
| Manufacturer | Heidelberg |
| Year | 2001 |
| Machine Availability | Less than 30 days |
| Machine Condition | Running |
| Price | On Request |
| Location | Italy |
About Heidelberg - Speedmaster SM 74-5 P
The Heidelberg Speedmaster SM 74-5 P is a high-performance sheet-fed offset printing press designed for commercial and industrial printing applications. This machine is part of the Speedmaster series, known for its exceptional print quality, reliability, and versatility. The SM 74-5 P is ideal for printing a wide range of materials, including paper, board, and plastics, and is commonly used in industries such as packaging, label printing, and commercial printing. Key features of this machine include its high-speed printing capabilities, advanced paper handling system, and precise registration control. The benefits of the SM 74-5 P include increased productivity, reduced waste, and exceptional print quality.
Key Technical Aspects:
Dimensions and Specifications : The Heidelberg Speedmaster SM 74-5 P has a length of 7,340 mm, a width of 2,440 mm, and a height of 2,240 mm. It weighs approximately 12,000 kg and has a maximum printing speed of 15,000 sheets per hour.
Paper Handling : The SM 74-5 P features a advanced paper handling system with a maximum sheet size of 740 x 1,040 mm and a minimum sheet size of 360 x 520 mm. It has a feeder capacity of 5,000 sheets and a delivery capacity of 5,000 sheets. The machine is equipped with a Preset Feeder, which allows for fast and precise sheet alignment, and a Pile Delivery System, which enables efficient and gentle sheet delivery.
Printing Unit : The printing unit of the SM 74-5 P features a maximum printing speed of 15,000 sheets per hour and a maximum printing pressure of 400 kN. It uses a conventional offset printing process with a resolution of 254 lpi. The machine is equipped with a range of printing units, including a 5-color unit, which allows for a wide range of printing applications.
Ink System : The SM 74-5 P uses a conventional offset ink system with a maximum ink flow rate of 1,200 kg/h. The machine is equipped with a InkLine ink supply system, which ensures consistent and precise ink flow, and an InkZone ink management system, which allows for real-time ink monitoring and control.
Plate Cylinder : The plate cylinder of the SM 74-5 P has a diameter of 740 mm and a circumference of 2,310 mm. It features a maximum plate thickness of 1.5 mm and a minimum plate thickness of 0.3 mm. The machine is equipped with a PlateLine plate changing system, which allows for fast and efficient plate changing, and a PlatePilot plate management system, which enables precise plate registration and control.
