Heidelberg - Speedmaster SM 52-5 LX ANICOLOR

Key Technical Aspects:

Dimensions and Specifications : The machine has a length of 6,350 mm, a width of 2,350 mm, and a height of 1,900 mm. It weighs approximately 6,500 kg and has a maximum sheet size of 520 x 740 mm. The press has a capacity of up to 15,000 sheets per hour.

Paper Handling : The Speedmaster SM 52-5 LX ANICOLOR features a feeder with a capacity of up to 5,000 sheets, and a delivery system with a pile height of up to 1,500 mm. The machine is equipped with a non-stop feeder and a non-stop delivery system, allowing for continuous printing and minimizing downtime.

Printing Unit : The printing unit is equipped with five printing units, each with a maximum printing speed of 15,000 sheets per hour. The machine uses a maximum plate size of 620 x 840 mm and has a printing resolution of up to 400 lpi. The printing technology used is sheet-fed offset, with a maximum impression cylinder diameter of 440 mm.

Ink System : The ANICOLOR inking technology uses a combination of liquid inks and a unique anilox roller system to achieve fast makeready, reduced waste, and improved color consistency. The ink system has a capacity of up to 20 kg per color, and features an automatic ink supply system and an ink temperature control system.

Plate Cylinder : The plate cylinder has a diameter of 440 mm and is designed for use with polyester or steel printing plates. The plate cylinder is equipped with a plate changing system, allowing for fast and easy plate changes.
