Heidelberg - Speedmaster SM 102 ZP

Key Technical Aspects:

Dimensions and Specifications : The Heidelberg Speedmaster SM 102 ZP has a length of 10,350 mm, a width of 2,350 mm, and a height of 2,150 mm. It weighs approximately 12,000 kg and has a maximum printing speed of 15,000 sheets per hour.

Paper Handling : The SM 102 ZP features a high-capacity feeder with a maximum pile height of 1,200 mm and a sheet size range of 360 x 520 mm to 1,020 x 1,450 mm. The machine is equipped with a double-sheet detection system and an anti-static device to ensure smooth paper flow. The delivery system has a maximum pile height of 1,200 mm and is equipped with a jogger and a pile transport system.

Printing Unit : The printing unit of the SM 102 ZP features a maximum printing format of 1,020 x 1,450 mm and a minimum printing format of 360 x 520 mm. It has a printing speed of up to 15,000 sheets per hour and a maximum printing pressure of 400 kN. The machine uses a three-cylinder arrangement with a transfer cylinder, an impression cylinder, and a plate cylinder.

Ink System : The SM 102 ZP uses a high-performance ink system with a maximum ink flow rate of 1,200 kg/h. The machine is equipped with a ductless ink system and an ink temperature control system, ensuring consistent ink flow and optimal printing results.

Plate Cylinder : The plate cylinder of the SM 102 ZP has a diameter of 1,020 mm and a circumference of 3,200 mm. It features a plate changing system with automatic plate clamping and a plate washing system, ensuring fast and efficient plate changes.
