Heidelberg - Speedmaster SM 102 F

Key Technical Aspects:

Dimensions and Specifications : The Heidelberg Speedmaster SM 102 F has a length of 23.6 ft (7.2 m), a width of 10.5 ft (3.2 m), and a height of 7.5 ft (2.3 m). It weighs approximately 44,000 lbs (20,000 kg) and has a maximum sheet size capacity of 28.7 x 40.2 in (729 x 1020 mm).

Paper Handling : The SM 102 F features a high-capacity feeder with a maximum pile height of 31.5 in (800 mm) and a sheet thickness range of 0.06-0.6 mm. The machine is equipped with a dual-circuit sheet guiding system, ensuring precise sheet alignment and registration. The delivery system features a high-speed pile Turner and a jogger for efficient sheet stacking.

Printing Unit : The printing unit of the SM 102 F is equipped with a maximum printing speed of 15,000 sheets per hour and a resolution of 300 lpi. The machine uses a conventional offset printing process with a maximum printing area of 28.7 x 40.2 in (729 x 1020 mm). The printing unit features a seven-color configuration, including a varnish unit, and is equipped with Heidelberg's renowned Alcolor dampening system.

Ink System : The SM 102 F uses a conventional offset ink system with a maximum ink flow rate of 12 kg/h. The machine is equipped with a seven-color ink system, including a varnish unit, and features Heidelberg's InkLine ink supply system for efficient ink management.

Plate Cylinder : The plate cylinder of the SM 102 F has a diameter of 4.3 in (109 mm) and a circumference of 13.4 in (340 mm). The machine features a plate changing system with a maximum plate size of 28.7 x 40.2 in (729 x 1020 mm) and a minimum plate size of 12.6 x 18.1 in (320 x 460 mm).
