Heidelberg - Speedmaster SM 102-5-P

Key Technical Aspects:

Dimensions and Specifications : The Heidelberg Speedmaster SM 102-5-P has a machine length of 23.62 ft (7.2 m), a machine width of 10.17 ft (3.1 m), and a machine height of 7.55 ft (2.3 m). The machine weighs approximately 44,000 lbs (20,000 kg) and has a maximum sheet size of 28.35 x 40.16 in (720 x 1020 mm).

Paper Handling : The SM 102-5-P features a high-performance paper handling system, including a feeder with a capacity of up to 10,000 sheets, an infeed system with a sheet alignment system, and a delivery system with a pile height of up to 5.9 ft (1.8 m). The machine is capable of handling paper weights ranging from 70-600 gsm.

Printing Unit : The printing unit of the SM 102-5-P features a maximum printing speed of up to 15,000 sheets per hour, with a printing resolution of 300 lpi. The machine uses a conventional offset printing process with a maximum printing area of 28.35 x 40.16 in (720 x 1020 mm).

Ink System : The SM 102-5-P uses a high-performance ink system with a maximum ink flow rate of 12 kg/h. The machine features a five-color ink system, with a maximum ink capacity of 20 kg per color.

Plate Cylinder : The plate cylinder of the SM 102-5-P has a diameter of 4.33 ft (1.32 m) and a circumference of 13.78 ft (4.2 m). The plate cylinder is designed for high-speed printing and features a precise plate clamping system for accurate plate registration.
