Heidelberg - GTO 46

Key Technical Aspects:

Dimensions and Specifications : The Heidelberg GTO 46 has a length of 5,350 mm, a width of 1,550 mm, and a height of 1,800 mm. It weighs approximately 4,500 kg and has a maximum sheet size of 460 x 320 mm. The press has a maximum printing speed of 10,000 sheets per hour.

Paper Handling : The GTO 46 features a high-capacity paper handling system with a feeder capacity of 3,000 sheets and a delivery capacity of 2,000 sheets. The press is equipped with a suction tape feeder and a sheet ejection system, ensuring smooth and efficient paper flow.

Printing Unit : The printing unit of the Heidelberg GTO 46 is equipped with a maximum of 5 printing units, each with a printing speed of up to 10,000 sheets per hour. The press uses a conventional offset printing process with a maximum printing resolution of 300 lpi. The printing unit features a quick-change inking system and a precision registration system for accurate color registration.

Ink System : The GTO 46 uses a conventional offset ink system with a maximum ink capacity of 20 kg per unit. The press features a ink train system with a triple-roller inking system and a ink fountain with a automatic ink supply system.

Plate Cylinder : The plate cylinder of the Heidelberg GTO 46 has a diameter of 220 mm and a circumference of 690 mm. The plate cylinder is designed for high-quality plate production and features a precision plate clamping system for accurate plate registration.
