Heidelberg - CD 102-6 LYYLX3 HYBRID

Sheet Fed / Offset Heidelberg CD 102-6 LYYLX3 HYBRID

Machine Specification

FeaturesValue
Number of colours6
Max sheet size40.2 x 28.3 inch | 102 x 72 cm

Machine Description

CP 2000 console touch screen, axial, circumferential and diagonal register remote control, ink ductors rotation control, job memorization.
CP 2000 MasterLevel.
Preset Plus Feeder.
Head feeder 3 more suctions for paper transport.
Front sensor on flap of the feeder.
Slow down : system to slow the sheet down then 65% on feeder.
Suction belt feeder with 3 sections of transport of sheets to the frontal registers.
Pneumatic side register control with integrated auto cleaning and double sheet control with direct system.
Non-Stop on feeder.
Multiple-sheet detector/ tear-off.
Multiple sheet control/Forwarding roller.
Ultrasonic double-sheet control.
Antistatic for foil on feeder.
No. 2 Eltex ion blowers on feeder.
Suction brush on feeder.
Air transfer System Venturi.
Roller wash-up device controlled by CP 2000.
Modular blanket cylinder washing device by CP 2000.
Modular impression cylinder washing device by CP 2000.
Autoplate.
Chromed blanket cylinders.
Alcolor Vario System damping.
CombiStar CAN : Technotrans ink temp control combined with damping refrigeration + Alcosmart; functions remote controlled by console.
ZDT preparation after unit 1°, 2°, 3°, 4°, 5°, 6°.
No. 3 x IST/UV interdeck dryers to put in all transfer positions (full flexibility).
No. 3 x IST/Hot Air interdeck dryers to put in all transfer positions (full flexibility).
No. 2 Varnishing units 550 l/h chambered doctor blades system with remote diagonal register and anilox rollers.
Varnishing metering last coating FLEXOKIT.
Preset Plus Delivery : a lot of preset functions and memorization, aereodinamic grippers system, slow down system by CP2000, panel in delivery.
CleanStar Compact : filter for powder spray suction.
DryStar Combination CanOpen 4 modules: slide-in (Pos.1) 6xIR/HL, slide-in (Pos. 2) HL, slide-in (Pos. 3) UV lamps 200w/cm, slide-in (Pos. 4) enviromental air.
Non-Stop in delivery.
PowderStar Weko AP 500.
Delivery with UV package.
Sheet slow-down device suction drum 9 mm.
AirStar : central air box water cooled.
ScrollStar : Atlas Copco compressor.
Technotrans Beta.t : Water refrigeration cabin for UV Dryer.
15.000 speed/h.
Intercom system: Microphone communication system.
UV basic equipment.
Unit 8° Y: DryStar with 1 IR lamps (fix) + 1 module IR/hot air (removable).
Unit 9° Y: DryStar with 1 IR lamps (fix) + 1 module IR/hot air (removable).
UV IST mod. D-108-3M/3x1-URS-HD-SLC-FLC-CAN

ModelHeidelberg-CD 102-6 LYYLX3 HYBRID
ManufacturerHeidelberg
Year2007
Machine AvailabilityImmediately from stock
Machine ConditionIn Stock
PriceOn Request
LocationItaly

About Heidelberg - CD 102-6 LYYLX3 HYBRID

The Heidelberg CD 102-6 LYYLX3 HYBRID is a high-performance, sheet-fed offset printing press designed for commercial and packaging printing applications. This machine is part of the CD 102 series, known for its exceptional print quality, flexibility, and productivity. The CD 102-6 LYYLX3 HYBRID offers a unique combination of conventional offset and UV printing capabilities, making it an ideal choice for printers who need to produce a wide range of applications, from high-end commercial print to specialty packaging. Key features of this press include its ability to handle a wide range of substrates, high-speed printing capabilities, and advanced automation features.

Key Technical Aspects:

Dimensions and Specifications : The Heidelberg CD 102-6 LYYLX3 HYBRID has a length of 23.62 ft (7.2 m), a width of 10.17 ft (3.1 m), and a height of 8.2 ft (2.5 m). The machine weighs approximately 44,000 lbs (20,000 kg) and has a maximum sheet size of 28.35 x 40.16 in (720 x 1020 mm).

Paper Handling : The CD 102-6 LYYLX3 HYBRID features a high-capacity feeder with a maximum pile height of 31.5 in (800 mm) and a sheet thickness range of 0.06-0.6 mm. The press is equipped with six printing units, each with a separate delivery system, and a maximum output of 15,000 sheets per hour.

Printing Unit : The printing unit of the CD 102-6 LYYLX3 HYBRID features a maximum printing speed of 15,000 sheets per hour, with a resolution of 254 lpi (100 l/cm). The press uses a combination of conventional offset and UV printing technologies, allowing for a wide range of applications and substrates.

Ink System : The CD 102-6 LYYLX3 HYBRID uses a hybrid ink system, combining conventional offset inks with UV inks. The press has a maximum ink capacity of 22.04 gal (83.5 L) and features an advanced ink management system for efficient ink usage and reduced waste.

Plate Cylinder : The plate cylinder of the CD 102-6 LYYLX3 HYBRID has a diameter of 4.33 in (110 mm) and features a maximum plate size of 28.35 x 40.16 in (720 x 1020 mm). The plate cylinder is designed for high-speed printing and features an advanced plate changing system for fast and efficient job changes.
