Horizon - StitchLiner System

Machine Description

We are pleased to offer:.
Used Horizon StitchLiner System Year 2006.
Specification.
Horizon StitchLiner line for saddle-stitched booklets, configured for continuous production with tower collating, accumulation and folding, saddle stitching, and in-line three-knife trimming..
.
The VAC-100 towers ensure stable, expandable vacuum-fed sheet feeding; the ACF-30 accumulator/folder assembles the set with controlled creasing and folding; the SPF-30 stitcher/folder performs precise saddle stitching; the HTS-30 trimmer executes the final three-knife cut; and the ST-40 stacker/by-pass unit allows high pile stacking, rejection of faulty sets, and continuous operation. The belt delivery and waste extraction system optimise workflow and cleanliness throughout the line..
.
An ideal system for commercial printers and publishers requiring precision, repeatability, and high productivity in brochures, magazines, and catalogues..
Includes:.
2× VAC-100 Collating Towers (VAC-100a & VAC-100m, 10 bins each, suction feed).
ST-40 Stack/By-pass Unit.
ACF-30 Accumulator/Folder.
SPF-30 Saddle-Stitcher/Folder.
HTS-30 3-Knife Trimmer (in-line).
Belt delivery system.
Waste extraction for trimmer.
.
Maximum speed: Up to 9,700 sets/hour (job dependent).
Sheet size range: Approx. 148 × 148 mm to 350 × 500 mm.
Maximum book thickness: Approx. 51 mm (trimmer).
Condition: Fully operational, well-maintained, in production.
Good working order.
Available immediately.
