Console
Machine Description
Centerline system for quick job changeover.
CUBE control system.
Antistatic bars for synthetic materials.
Pull lay operator side.
Pull lay operator opposite side.
Slip at the feeder to avoid digging on the floor.
Cutting plate with micrometric adjustment for 1 mm thin plates.
Outside table for the preparation of the stripping unit.
1 upper pull-out frame quick lock.
1 Die-cutting chase quick lock.
1 central stripping quick lock.
Cutting plate with micrometric adjustment for 1 mm thin plates.
1 die-cutting frame with quick tightening.
1 Die-cutting chase.
Non-stop delivery with grill.
Slip at the delivery to avoid digging on the floor.
7.700 speed/h (depending on cardboard and type of iob feature).
Board quality processable : carta (min. 80g/m²); cartone (250/2000 g/m²); corrugate* (3 - 4 mm.) ( * ) Carton acceptable warp : 4% of the widthwise sheet.
Cutting force 260 TON.
Hot Plast: hot die-cutting system for plastic supports.
Paper 80/90 g/m2 - Corrugate 4 mm
| Model | Bobst-SPERIA 106 E |
|---|---|
| Manufacturer | Bobst |
| Year | 2004 |
| Machine Availability | Immediately from stock |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Italy |
About Bobst - SPERIA 106 E
The Bobst SPERIA 106 E is a high-performance die-cutting machine designed for the packaging and printing industry. This machine is categorized as a flatbed die-cutter, primarily used for cutting and creasing various materials such as paperboard, corrugated cardboard, and plastic sheets. The SPERIA 106 E is renowned for its precision, speed, and versatility, making it an ideal solution for manufacturers of folding cartons, blister packs, and other packaging products. Its key features include a robust construction, advanced automation, and a high level of customization, allowing users to optimize their production workflow and improve overall efficiency.
Key Technical Aspects:
Dimensions and Specifications : The Bobst SPERIA 106 E has a machine length of 4,500 mm, a machine width of 2,200 mm, and a machine height of 2,300 mm. It weighs approximately 12,000 kg and has a maximum sheet size capacity of 1,060 mm x 760 mm.
Paper Handling : The SPERIA 106 E features a high-capacity feeder with a maximum pile height of 1,200 mm, allowing for efficient processing of large batches. The machine is equipped with a precision-controlled sheet alignment system and a high-speed delivery system, ensuring accurate and rapid processing of cut and creased sheets.
Die-Cutting Unit : The die-cutting unit is equipped with a high-precision, servo-driven system, allowing for accurate and repeatable cutting and creasing operations. The machine has a maximum cutting force of 400 tons and a cutting speed of up to 7,500 sheets per hour.
Ink System : Not applicable, as the Bobst SPERIA 106 E is a die-cutting machine and does not utilize an ink system.
Plate Cylinder : The plate cylinder is designed for precise and efficient die-cutting operations, featuring a diameter of 1,060 mm and a maximum plate thickness of 24 mm. The cylinder is equipped with a quick-lock system, allowing for rapid plate changes and minimizing downtime.
