Collator and booklet production Machinery for Sale | Preowned & Preloved

Gathering and collating

Horizon VAC-600 HC collator (2016) in excellent working condition, fully operational and ready for production. Air suction feeding system ensures accurate handling across a wide range of paper types. Modular configuration with 6 bins (expandable up to 36), ideal for high-volume environments. Production speed of up to 9,900 sets per hour, featuring a “Touch and Work” control panel and job memory for increased efficiency. Compatible with Horizon finishing systems, including bookletmaking and saddle stitching. Contact us for further details and pricing

Hampshire

United Kingdom

Gathering and collating

- collator AC-6000 with - cover feeder CF-20 Horizon AC-6000 collator - model: air-suction collator - bins: 6 - error avoidance: misfeed-, doublefeed- and jamming control programs: - doublecycle (nonstop-work) - inject (simply and doubly) - booklet making program - selective collating - sheet size: max. 470x318mm; min. 210x148mm - processing strength: 50-260g/sqm - loading height: 100mm/ bin - production speed: max. 2.400 cycles/h - power: 400V - 1,86kW - dimension: 1650x650x1650mm - weight: 400kg We can also organize the following for you: packaging, loading, transport ( by ship or plane) including customs LA-POSTPRESS Germany LA-POSTPRESS Verified dealer Manufacturer: Horizon Model: AC - other models Year: 1992 Stations: 6 Size: 2090 x 1230 mm.

Unterfranken

Germany

22915

Gathering and collating

- Horizon CCR CCR= criss cross delivery unit - only with A4 reversible box suitable for: Horizon HAC-15a / HAC-15b Horizon AC-8000 / AC-8000s Horizon TAC-8a / TAC-8b Horizon AC-1200a / AC-1200b Horizon MC-8a / MC-8c Horizon MAC-8a / MAC-8c Horizon MC-80a / MC-80c Horizon VAC-100a / VAC-100c Horizon VAC-60a / VAC-60c Horizon VAC-1000a / VAC-1000c Horizon VAC-600a / VAC-600c weight: 49kg

Unterfranken

Germany

22908

Gathering and collating

Criss Cross delivery unit suitable for: Horizon AC-8000 Horizon AC-6000 Horizon MAC-8 - Sheet Size: max. 148 x 210 mm to 318 x 410 mm - Pile Sheet: max. 120 mm - Criss Cross Mechanism: Cam mechanism in sync with collating signal from collator - Power: 100 V/60 W Connected to AC-6000, AC-8000S or AC-8300 - Dimensions: 570 x 500 x 380 mm - Weight: 20 kg

Unterfranken

Germany

10361

Gathering and collating

- manual device HMU-80 Horizon HMU-80 manual device - compatibel with: Horizon MC-80a / MC-80m / MC-80c - weight: 8,8kg

Unterfranken

Germany

10346

Booklet machines

- short conveyor SC-20 Horizon SC-20 short conveyor - compatibel with: Horizon FC-20/ FC-20A - weight: 11kg

Unterfranken

Germany

10285

Booklet machines

offer consist of: - short conveyor SC-10 Horizon SC-10 short conveyor - compatibel with: Horizon FC-10/ FC-11

Unterfranken

Germany

23079

Booklet machines

Horizon VAC-100a SPF-20 FC-20 Booklet Making System, used The Horizon VAC-100a SPF-20 FC-20 system is a powerful solution for professional booklet production, combining collating, stitching, folding, and front trimming in one efficient process. Special features: - Number of collating stations: 10 - Versatile stitching options: Saddle, corner, and side stitching possible - Expandable stitching heads: Upgradable from 2 to up to 4 stitching heads for increased flexibility - Touch & Work: Intuitive operation thanks to user-friendly technology - Programmable memory: 9 memory slots for repeat jobs - Precise error control: Prevention of miss, double-feed, and jam problems Technical specifications: - Paper size: max. 500 x 350 mm; min. 148 x 120 mm - Booklet size: max. 230 x 320 mm; min. 85 x 98 mm - Paper weight: 40-250 g/m² - Processing thickness: 2-20 sheets (80 g/m²) - Trimming thickness: 4-80 pages (80 g/m²) - Face trim: max. 15 mm - Production speed: max. 3,500 booklets/h - Collating performance: up to 9,500 sets/h - Loading capacity per station: 55 mm - Power supply: 230V; 50Hz - Total power consumption: approx. 1.86 kW

Unterfranken

Germany

23091

Gathering and collating

Collating Tower with Suction and Air HORIZON VAC-100a, 10 Stations, used Key Features - Efficient and Reliable: The Horizon VAC-100a is designed for demanding environments. It ensures your collating jobs are completed quickly and efficiently - Touch & Work: Thanks to 'Touch & Work' technology, the VAC-100a is easy and intuitive to operate - Memory: The machine has 9 programmable memory slots for repeat jobs, saving you time and effort - Accuracy and Precision: Say goodbye to miss-feed, double-feed, and jam problems. The VAC-100a offers error prevention controls to ensure each set is perfectly collated Specifications - Format: max. 500x350mm; min. 148x120mm - Paper weight: 40-250g/sqm - Performance: up to 9,500 sets/h - Loading capacity: 55mm/station - Power: 230V; 50Hz - 1.86kW - Dimensions: 842x652x1,961mm - Weight: 310kg

Unterfranken

Germany

23124

Gathering and collating

Used Horizon VAC-60Hc Collating Tower, used The Horizon VAC-60Hc is a powerful collating tower designed for efficient and reliable paper handling in professional print finishing environments. Key Features: - Loading capacity: 130 mm per bin - Modular design: tower with 6 feed stations, expandable up to 6 towers for a total of 36 stations - Suction and air-blow technology: Uses Horizon's advanced technology for consistent and reliable sheet feeding with various paper types and weights - Versatile paper processing: Handles sheets from 148 x 120 mm to 500 x 350 mm, with paper weights from 40 to 250 g/m² - High production speed: Up to 9,500 sets per hour, depending on paper size and configuration - User-friendly operation: Intuitive interface for easy job setup and control - Advanced error prevention: Equipped with miss-feed, double-feed, and jam detection for improved accuracy and reliability - Job memory: Ability to store recurring jobs for increased efficiency Technical Specifications: - Dimensions: 842 x 652 x 1,961 mm - Weight: 310 kg - Power supply: 230V, 50/60Hz - 1.86kW

Unterfranken

Germany

23123

Gathering and collating

HORIZON VAC-60Ha Collator, used The Horizon VAC-60Ha is a powerful air-suction collating tower designed for efficient and reliable paper handling in professional print finishing environments. Key Features - Modular Design: The VAC-60Ha is a single tower with 6 feeding stations, expandable up to 6 towers for a total of 36 stations - Air-Suction Feeding System: Uses Horizon's advanced suction technology for consistent and reliable sheet feeding with various paper types and weights - Versatile Paper Handling: Processes sheets from 148 x 120 mm to 500 x 350 mm, with paper weights from 40 to 250 g/m² - High Production Speed: Achieves speeds up to 9,500 sets per hour, depending on paper size and setup - User-Friendly Operation: Features "Touch & Work" technology for easy operation and job setup - Advanced Error Prevention: Equipped with misfeed, double-feed, and jam control for improved accuracy and reliability - Job Memory: 9 memory slots for recurring jobs, increasing efficiency for frequent setups Technical Specifications - Dimensions: 842 x 652 x 1,961 mm - Weight: 310 kg - Power Supply: 230V, 50/60Hz - 1.86kW - Loading Height: 130 mm per station

Unterfranken

Germany

23112

Gathering and collating

Used Horizon MC-8a Collator The Horizon MC-8a is a proven collator that can be combined with other modules such as stapling, folding, and cutting units to enable brochure production. Special Features: - Number of stations: 8 - Robust and cost-effective - Modular design: Can be combined with other Horizon modules to form a complete brochure production line. Technical Specifications: - Paper sizes: From A5 to A3 (5.8" x 8.3" to 12.5" x 18.5") - Paper weight: 52 g/m² to 260 g/m² - Sorting speed: Up to 3,500 sets per hour (at A4) - Maximum sheet size: 317 mm x 470 mm

Unterfranken

Germany

23113

Gathering and collating

Used Horizon MC-8m Collator: Reliability at Low Investment The Horizon MC-8m is a proven model from Horizon that has been on the market since the 1990s. Despite its age, it offers impressive reliability and efficiency, making it an attractive option for companies seeking cost-effective solutions. Special Features: - Number of Stations: 8 - Reliability: Robust construction and capable of stable operation over long periods - Cost-effective: Compared to newer models, the MC-8m offers a budget-friendly alternative without sacrificing essential functions Technical Details: - Maximum Paper Size: 470 x 318 mm (max.) and 160 x 110 mm (min.) - Paper Weight: 50-260 g/m² - Performance: Up to 5,100 per hour - Power Supply: 400V - Approximately 229 kg

Unterfranken

Germany

23152

Gathering and collating

Used Horizon VAC-60Ha Collator The Horizon VAC-60Ha is a powerful collator designed as an expansion or single module for existing Horizon collating systems. This machine offers a range of features that make it a valuable component in the printing and publishing industry. Special Features: - The VAC-60Ha is designed as an single or additional tower to increase the capacity of existing systems - Number of Stations: 6 collating stations - Paper Handling: Processes sheets from 120 x 148 mm to 350 x 500 mm, with paper weights from 40 to 300 g/m² - Processing Speed: Supports system speeds of up to 10,000 sets per hour - Integration: Seamlessly integrates into existing VAC systems Technical Specifications: - Dimensions: 842 x 652 x 1,962 mm - Weight: Approximately 315 kg - Power Connection: 230V, 50/60Hz - Loading Height: 130 mm per station

Unterfranken

Germany

23153

Gathering and collating

Used Horizon VAC-60Hc Collating Tower, used The Horizon VAC-60Hc is a powerful collating tower designed for efficient and reliable paper handling in professional print finishing environments. Key Features: - Loading capacity: 130 mm per bin - Modular design: Tower with 6 feed stations, expandable up to 6 towers for a total of 36 stations - Suction and air-blow technology: Uses Horizon's advanced technology for consistent and reliable sheet feeding with various paper types and weights - Versatile paper processing: Handles sheets from 148 x 120 mm to 500 x 350 mm, with paper weights from 40 to 250 g/m² - High production speed: Up to 9,500 sets per hour, depending on paper size and configuration - User-friendly operation: Intuitive interface for easy job setup and control - Advanced error prevention: Equipped with miss-feed, double-feed, and jam detection for improved accuracy and reliability - Job memory: Ability to store recurring jobs for increased efficiency Technical Specifications: - Dimensions: 842 x 652 x 1,961 mm - Weight: 310 kg - Power supply: 230V, 50/60Hz - 1.86kW

Unterfranken

Germany

70219

Booklet machines

Horizon HOF-400, fully automatic feeder, used. This robust, fully automatic feeder was specially developed for the offline production of digitally printed booklets in conjunction with the SPF-200A, SPF-200L booklet making units, the StitchLiner 5500 and other optional additional devices. The sheets are removed sheet by sheet, checked, grouped and fed to the downstream unit in a block. Mark reading ensures reliable grouping and the production of brochures in different sizes. Special features: - Maximum flexibility at an extremely attractive price-performance ratio - Reliable paper feed thanks to suction belt feed - Extremely short set-up times thanks to fully automatic format adjustment - Extremely easy operation and set-up in seconds thanks to TOUCH&WORK technology - Economical processing of small and medium volumes in top quality Technical specifications: - Infeed format 4-sided sheets min. 203 x 203 mm, max. 610 x 356 mm (depending on downstream unit) - Paper thickness 50 - 160 g/sqm for normal paper / 70 - 160 g/sqm for coated paper - Loading capacity max. 620 mm - Speed A3 format max. 25,000 sheets/h - A4 format speed max. 35,000 sheets/h / max. 45,000 sheets/h (landscape) - Weight 782 kg (with front cutter FC-200A) - Machine dimensions 960 mm x 1,050 mm x 936 mm (LxWxH) - Power supply 400 V 1.8 A, 1.0 kW

Unterfranken

Germany

70219

Booklet machines

Horizon HOF-400, fully automatic feeder, used. This robust, fully automatic feeder was specially developed for the offline production of digitally printed booklets in conjunction with the SPF-200A, SPF-200L booklet making units, the StitchLiner 5500 and other optional additional devices. The sheets are removed sheet by sheet, checked, grouped and fed to the downstream unit in a block. Mark reading ensures reliable grouping and the production of brochures in different sizes. Special features: - Maximum flexibility at an extremely attractive price-performance ratio - Reliable paper feed thanks to suction belt feed - Extremely short set-up times thanks to fully automatic format adjustment - Extremely easy operation and set-up in seconds thanks to TOUCH&WORK technology - Economical processing of small and medium volumes in top quality Technical specifications: - Infeed format 4-sided sheets min. 203 x 203 mm, max. 610 x 356 mm (depending on downstream unit) - Paper thickness 50 - 160 g/sqm for normal paper / 70 - 160 g/sqm for coated paper - Loading capacity max. 620 mm - Speed A3 format max. 25,000 sheets/h - A4 format speed max. 35,000 sheets/h / max. 45,000 sheets/h (landscape) - Weight 782 kg (with front cutter FC-200A) - Machine dimensions 960 mm x 1,050 mm x 936 mm (LxWxH) - Power supply 400 V 1.8 A, 1.0 kW

Unterfranken

Germany

23167

Gathering and collating

Air suction collator HORIZON VAC-100a, 10 Stations, used Key Features - Efficient and Reliable: The Horizon VAC-100a is designed for demanding environments. It ensures your collating jobs are completed quickly and efficiently - Touch & Work: Thanks to 'Touch & Work' technology, the VAC-100a is easy and intuitive to operate - Memory: The machine has 9 programmable memory slots for repeat jobs, saving you time and effort - Accuracy and Precision: Say goodbye to miss-feed, double-feed, and jam problems. The VAC-100a offers error prevention controls to ensure each set is perfectly collated Specifications - Format: max. 500x350mm; min. 148x120mm - Paper weight: 40-250g/sqm - Performance: up to 9,500 sets/h - Loading capacity: 55mm/station - Power: 230V; 50Hz - 1.86kW - Dimensions: 842x652x1,961mm - Weight: 310kg

Unterfranken

Germany

70236

Gathering and collating

Collator TMF N10 • Model: TMF N10 • Paper format: from 105 x 148 mm to 500 x 700 mm • Capacity: 10 stations • Includes vibrating table, compressor • Condition: Fully functional • Special features: Front rollers are new

Unterfranken

Germany

23175

Gathering and collating

Horizon MC-80m Collator, Used The Horizon MC-80m is a proven and cost-effective collator known for its reliability and ease of use. As an older model, it offers an economical solution for print shops and binderies looking for solid performance at an attractive price. Key Features: - Modular design: Expandable and compatible with other Horizon systems - Vacuum feeding for precise and reliable sheet feeding - User-friendly control panel for easy setup and operation - Integrated double sheet detection to prevent errors - Automatic error sheet detection and ejection for uninterrupted production - Compatible with various paper qualities and formats Technical Specifications: - Station capacity: 8 stations - Max. sheet size: 350 x 500 mm - Min. sheet size: 148 x 210 mm - Paper weight: 52 - 300 g/m² - Stack height per station: up to 80 mm - Production speed: up to 8,000 sets per hour - Power supply: 230 V, 50/60 Hz - Dimensions (L x W x H): approx. 920 x 750 x 1960 mm - Weight: approx. 400 kg

Unterfranken

Germany

23176

Gathering and collating

Collating Tower for Expansion, Horizon VAC-1000m, 10 Stations The Horizon VAC-1000m tower is an expansion module for the VAC-1000 system designed to increase the capacity of collating machines. Unlike the VAC-1000a tower, the VAC-1000m does not have its own display and is solely intended for expansion purposes. Key Features - Number of Stations: 10 - Modular Expansion: The VAC-1000m can be used in conjunction with a VAC-100a tower to reach up to 60 stations, allowing adaptation to different production volumes. - Suction and Air-Blow System: Like the VAC-1000a, the VAC-1000m uses the patented rotating vacuum feed system with air-blow support to ensure reliable paper feeding with various paper qualities. - Integration: The VAC-1000m seamlessly integrates into existing Horizon systems to enhance efficiency and flexibility. Specifications - Maximum Sheet Size: 350 x 500 mm - Minimum Sheet Size: 148 x 120 mm - Loading Capacity: 55 mm per station - Weight: 310 kg per tower - Power Supply: 230 V, 2.3 kW

Unterfranken

Germany

23183

Gathering and collating

Used Horizon VAC-60Ha Collator The Horizon VAC-60Ha is a powerful collator designed as an expansion or single module for existing Horizon collating systems. This machine offers a range of features that make it a valuable component in the printing and publishing industry. Special Features: - The VAC-60Ha is designed as an additional or single tower to increase the capacity of existing systems - Number of Stations: 6 collating stations - Paper Handling: Processes sheets from 120 x 148 mm to 350 x 500 mm, with paper weights from 40 to 300 g/m² - Processing Speed: Supports system speeds of up to 10,000 sets per hour - Integration: Seamlessly integrates into existing VAC systems Technical Specifications: - Dimensions: 842 x 652 x 1,962 mm - Weight: Approximately 315 kg - Power Connection: 230V, 50/60Hz - Loading Height: 130 mm per station

Unterfranken

Germany

23184

Gathering and collating

Used Horizon VAC-60Hc Collator, used The Horizon VAC-60Hc is a powerful collator designed for efficient and reliable paper handling in professional print finishing environments. Key Features: - Loading capacity: 130 mm per bin - Modular design: Tower with 6 feed stations, expandable up to 6 towers for a total of 36 stations - Suction and air-blow technology: Uses Horizon's advanced technology for consistent and reliable sheet feeding with various paper types and weights - Versatile paper processing: Handles sheets from 148 x 120 mm to 500 x 350 mm, with paper weights from 40 to 250 g/m² - High production speed: Up to 9,500 sets per hour, depending on paper size and configuration - User-friendly operation: Intuitive interface for easy job setup and control - Advanced error prevention: Equipped with miss-feed, double-feed, and jam detection for improved accuracy and reliability - Job memory: Ability to store recurring jobs for increased efficiency Technical Specifications: - Dimensions: 842 x 652 x 1,961 mm - Weight: 310 kg - Power supply: 230V, 50/60Hz - 1.86kW

Unterfranken

Germany

70247

Booklet machines

- punch unit HP-200A Horizon HP-200A punch unit - features: press- and punch - numbers of holes: max. 4 holes; min. 2 holes - punch hole position: max. 14mm; min. 9mm - punch hole diameter: 6mm - size: max. 356x508mm; min. 120x90mm - punch thickness: max. 4mm - speed: max. 4000 Broschüren/h - power: 230V / 50Hz - 0,68kW - dimensions: 500x770x1035mm - weight: 168kg

Unterfranken

Germany

70262

Booklet machines

Horizon Booklet Production Line SPF-200L, FC-200L, VAC-600Ha, VAC-600Hm, VAC-600Hm, VAC-600Hc The Horizon booklet production line featuring the models SPF-200L, FC-200L, is a state-of-the-art, modular solution for the efficient production of saddle-stitched booklets – including A4 landscape format. The system is suitable for both offset and digital printing and is especially designed for small to medium print runs. Thanks to the combination of collating machines (VAC-600Ha, VAC-600Hm, VAC-600Hm, VAC-600Hc), booklet maker (SPF-200L), and front trimmer (FC-200L), the line offers maximum flexibility and productivity in post-press processing. Special Features - Automated Settings: All format and production parameters are automatically set via a large, intuitive color touchscreen – including fold roller gap. - A4 Landscape Capability: The SPF-200L enables the production of booklets in A4 landscape format, making it particularly versatile. - Modular Expandability: The VAC-600 collating towers are modularly expandable from 6 up to 60 stations and allow non-stop operation through double-cycle and insert programs. - High Speed: Up to 9,500 cycles/hour for collating and up to 4,000 booklets/hour for stitching (3,500 in landscape format). - Flexible Configuration: Can be combined with additional Horizon feeders and digital print feeders for hybrid production lines. - Versatile Formats: Processes formats from at least 148 x 120 mm up to a maximum of 610 x 350 mm (SPF-200L). - Robust Wire Processing: Various stitching heads available for different wire gauges and loop stitching. - Easy Operation: Large touchscreens on all main modules for rapid setup and error diagnosis. Technical Specifications - SPF-200L Format Range (min-max): min. 180 x 105 mm, max. 610 x 350 mm - SPF-200L Speed: up to 4,000 cycles/h (3,500 cycles/h landscape) - SPF-200L Features: A4 landscape, fully automatic - FC-200L Format Range (min-max): Front trimmer, integrated - FC-200L Features: Final trimming - VAC-600a/c Format Range (min-max): min. 148 x 120 mm, max. 500 x 350 mm - VAC-600a/c Speed: up to 9,500 cycles/h - VAC-600a/c Number of Stations: 6–60 - VAC-600a/c Features: Modularly expandable, non-stop - Booklet Thickness: up to 100 pages (depending on paper) - VAC-600 Loading Capacity: 55 mm per station - Weight SPF-200L with FC-200L: approx. 831 kg - Machine Dimensions SPF-200L with FC-200L: 4,271 x 810 x 1,250 mm (L x W x H) - Power Supply: 230 V, 5.3 A; 1.0 kW (SPF-200L)

Unterfranken

Germany

10420

Gathering and collating

Criss Cross delivery unit suitable for: Horizon AC-8000 Horizon AC-6000 Horizon MAC-8 - Sheet Size: max. 148 x 210 mm to 318 x 410 mm - Pile Sheet: max. 120 mm - Criss Cross Mechanism: Cam mechanism in sync with collating signal from collator - Power: 100 V/60 W Connected to AC-6000, AC-8000S or AC-8300 - Dimensions: 570 x 500 x 380 mm - Weight: 20 kg

Unterfranken

Germany

10422

Gathering and collating

- expansion kit right conveyor CTK-100 Horizon CTK-100 c-Tower Kit extra function: collating to both sides - compatibel with: Horizon VAC-100a Horizon VAC-60Ha - weight: 5,52kg

Unterfranken

Germany

23191

Gathering and collating

Air suction collator HORIZON VAC-100a, 10 Stations, used Key Features - Efficient and Reliable: The Horizon VAC-100a is designed for demanding environments. It ensures your collating jobs are completed quickly and efficiently - Touch & Work: Thanks to 'Touch & Work' technology, the VAC-100a is easy and intuitive to operate - Memory: The machine has 9 programmable memory slots for repeat jobs, saving you time and effort - Accuracy and Precision: Say goodbye to miss-feed, double-feed, and jam problems. The VAC-100a offers error prevention controls to ensure each set is perfectly collated Specifications - Format: max. 500x350mm; min. 148x120mm - Paper weight: 40-250g/sqm - Performance: up to 9,500 sets/h - Loading capacity: 55mm/station - Power: 230V; 50Hz - 1.86kW - Dimensions: 842x652x1,961mm - Weight: 310kg

Unterfranken

Germany

23198

Gathering and collating

Horizon collator VAC-100c offer consists of: - air suction collator VAC-100c Horizon VAC-100c air-suction collator - technology: touch & work - model: air-suction collator - bins: 10 - error avoidance: misfeed-,doublefeed- and jamming control - saveable jobs: 9 memories for repeat orders - extensibility: up to 6 collators (60 bins) programs: - doublecycle (nonstop-work) - inject (simply and doubly) - booklet making program - block program - selective collating - sheet size: max. 500x350mm; min. 148x120mm - paper weight: 40-250g/sqm - production speed: max. 9.500 cycles/h - loading height: 55mm/ bin - power: 230V; 50/60Hz - 1,86kW - dimension: 842x652x1.961mm - weight: each 310kg - extra function Horizon VAC 100c: collating to both sides collator usable separately

Unterfranken

Germany

23200

Booklet machines

Horizon booklet maker VAC-100 a VAC-100 m SPF-20 A FC-20 A offer consists of: - air suction collator VAC-100a - air suction collator VAC-100m - stitching and folding SPF-20A - frontcutter FC-20A Horizon VAC-100a / Horizon VAC-100m air-suction collators - technology: touch & work - model: air-suction collator - bins: 10 each collator - error avoidance: misfeed-,doublefeed- and jamming control - saveable jobs: 9 memories for repeat orders - extensibility: up to 6 collators (60 bins) programs: - doublecycle (nonstop-work) - inject (simply and doubly) - booklet making program - block program - selective collating - sheet size: max. 500x350mm; min. 148x120mm - paper weight: 40-250g/qm - loading height: 55mm/ bin - production speed: max. 9.500 cycles/h - power: 230V/50Hz - 1,86kW - dimensions: 842x652x1.961mm - weight: 310kg Horizon SPF-20A stitcher and folder: - format adjustment: fully automatic - DIN-size and standard fold types: preassigned - saveable jobs: 12 memories for special sheet sizes + all DIN sheet sizes - stitching heads: 2 - expandable up to 4 stitching heads - stapling options: top-, side-, cornerstitiching - ring eylete stitiching: with ring eyelet stitching heads possible - inlet format: max. 500x350mm; min. 180x120mm - processing strength: min. 2 pages; max. 22 pages (80g/sqm) - clip distance: min. 73mm - stitching wire: 26 - 28 - production speed: max. 3.600 cycles/h - power: 230V/50Hz - 0,45kW - dimensions: 2.710x810x1.070mm - weight: 490kg Horizon FC-20A fore-edge trimmer: - counter - faulty set ejection - booklet size: max. 250x20mm; min. 85mm - size front cut: max. 20mm - trimming thickness: min. 4 pages / max. 88 pages (80g/sqm) - production speed: max. 3.400 cycles/h - power: 230V/50Hz - 0,2kW - dimensions: 610x810x1.070mm - weight: 240kg

Unterfranken

Germany

23192

Gathering and collating

Horizon VAC-100m Air-Suction Collator Tower The VAC-100m is the ideal solution for print shops looking to expand their production capacity without investing in completely new systems. Its easy integration with the VAC-100a tower and high reliability make it a valuable addition to your production line. Key Features: Cost-efficiency: The VAC-100m is a cost-effective expansion solution as it operates without its own display and control unit. This reduces acquisition costs and allows you to expand existing systems efficiently. Expandable Capacity: With the ability to connect up to 5 VAC-100m towers to one VAC-100a tower, you can flexibly expand your collating capacity to up to 60 stations. This enables efficient handling of large jobs and a significant increase in your production capacity. Reliability: With error prevention features such as misfeed, double-feed, and jam control, the VAC-100m ensures that your production runs smoothly and without interruptions. Specifications: - Technology: Touch & Work (via VAC-100a) - Number of stations: 10 per tower - Expandability: Up to 6 towers (60 stations) - Error prevention: Misfeed, double-feed, and jam control - Job memory: 9 storage slots for repeat orders - Programs: Double cycle (non-stop operation), sheet insertion (single and double), booklet making program, block program, selective collating - Sheet size: Max. 500x350 mm; Min. 148x120 mm - Paper weight: 40-250 g/m² - Loading capacity: 55 mm per station - Performance: Up to 9,500 sets/h - Power: 230V; 50/60Hz - 1.86 kW - Dimensions: 842x652x1,961 mm - Weight: 310 kg

Unterfranken

Germany

23210

Booklet machines

Horizon booklet maker SPF-20 A FC-20 A offer consists of: - stitching and folding SPF-20A - frontcutter FC-20A Horizon SPF-20A stitcher and folder: - format adjustment: fully automatic - DIN-size and standard fold types: preassigned - saveable jobs: 12 memories for special sheet sizes + all DIN sheet sizes - stitching heads: 2 - expandable up to 4 stitching heads - stapling options: top-, side-, cornerstitiching - ring eylete stitiching: with ring eyelet stitching heads possible - inlet format: max. 500x350mm; min. 180x120mm - processing strength: min. 2 pages; max. 22 pages (80g/sqm) - clip distance: min. 73mm - stitching wire: 26 - 28 - production speed: max. 3.600 cycles/h - power: 230V/50Hz - 0,45kW - dimensions: 2.710x810x1.070mm - weight: 490kg Horizon FC-20A fore-edge trimmer: - counter - faulty set ejection - booklet size: max. 250x20mm; min. 85mm - size front cut: max. 20mm - trimming thickness: min. 4 pages / max. 88 pages (80g/sqm) - production speed: max. 3.400 cycles/h - power: 230V/50Hz - 0,2kW - dimensions: 610x810x1.070mm - weight: 240kg

Unterfranken

Germany

23214

Slitter/cutter/creaser

- high performance-finisher DocuCutter DC-645 Duplo DocuCutter DC-645 high performance-finisher for digital color printing: - feeder: air-suction feeder with lining up - operation: by LCD-display - control: barcode control - PC included - saveable jobs: 80 memories for repeat orders - error avoidance: ultrasonic-doublefeed control eject gate testprogram print mark reader - integrated knives: 6 lengthwise knives + 1 cross knife - size: max. 650x370mm min. 210x210mm - paper weight: 110-350g/qm - loading height: 100mm - creasing each sheet: max. 10 - production speed: max. 1500 sheets/h (A4) max. 720 sheets/h (A3) - power: 230V / 50Hz - 0,3kW - dimensions: 2.240x750x1.115mm - weight: 360kg

Unterfranken

Germany

23211

Gathering and collating

HORIZON VAC-60Ha / Hm / Hc Collators The Horizon VAC-60 series (Ha, Hm, Hc) are modular air-suction collators designed for professional print finishing, offering precise, fast, and reliable sheet handling. Key Features Modular system: Each collator includes 6 feeding stations; expandable up to 6 towers (36 stations total). Advanced air-suction feeding: Ensures consistent and reliable sheet transport for a wide paper range. Flexible format range: Handles sheets from approx. 120 × 148 mm to 500 × 350 mm, with paper weights from 40–300 g/m². High-speed productivity: Processes up to 9,500–10,000 sets per hour, depending on setup. User-friendly operation: Models Ha and Hc feature “Touch & Work” technology for quick setup and control. Efficient integration: Model Hm serves as an expansion module without its own controls. Error prevention: Equipped with sensors for misfeed, double-feed, and jam detection. Job memory: Up to 9 programmable settings for recurring jobs. Technical Specifications Dimensions: approx. 842 × 652 × 1,961 mm Weight: about 310–315 kg Power supply: 230V, 50/60Hz, 1.86 kW Loading height: 130 mm per station

Unterfranken

Germany

23208

Gathering and collating

Horizon MC-80a | 3x MC-80m | Spare Parts | Partial Function

Unterfranken

Germany

23207

Booklet machines

Horizon VAC-100a VAC-100m SPF-20A FC-20A Booklet Making System, Used This Horizon booklet making system is a powerful solution for professional booklet production, combining collating, stitching, folding, and front trimming in an efficient process. It offers high productivity, versatile applications, and easy operation for efficient booklet production. Key Features: - Two collating towers: VAC-100a and VAC-100m with 10 stations each - Versatile stitching options: Saddle, corner, and side stitching possible - Touch & Work: Intuitive operation thanks to user-friendly technology - 9 programmable memory locations for repeat jobs - Precise error control: Prevention of miss-feed, double-feed, and jam problems - Expandable configuration: Possibility to add more VAC-100 towers Technical Specifications: - Paper format: max. 350 x 500 mm; min. 148 x 120 mm - Booklet format: max. 250 x 350 mm; min. 85 x 120 mm - Paper weight: 40-300 g/m² - Processing thickness: 2-22 sheets (80 g/m²) - Trimming thickness: 4-50 sheets (80 g/m²) - Front trim: max. 25 mm - Production speed: max. 3,600 booklets/h - Collating performance: up to 9,900 sets/h - Loading capacity per station: 55 mm - Power supply: 230V; 50/60Hz - Total power consumption: approx. 2.3 kW

Unterfranken

Germany
