Machine Description
We are pleased to offer:.
Used Duplo DPB-500 EVA Binder Year 2007.
Specification.
Counter: 0015627.
The Duplo DPB-500 EVA Binder is a fully automatic single-clamp perfect binding machine designed for efficient and high-quality softcover book production. Using EVA hot-melt adhesive, it delivers strong, consistent binding results and is particularly well suited to short-to-medium production runs, digital print environments and print-on-demand applications..
This model combines automated set-up, effective spine preparation and precise glue application, ensuring professional binding quality with minimal operator intervention. The DPB-500 is widely used by commercial printers and book manufacturers for producing paperbacks, manuals, catalogues and instructional materials..
Maximum Production Speed: Up to 525 books per hour.
Book Thickness: Min. 1 mm – Max. 51 mm (excluding cover).
Book Size (Spine × Fore-Edge): Max. 360 mm × 320 mm / Min. 120 mm × 120 mm.
Cover Size: Max. 360 mm × 696 mm / Min. 120 mm × 250 mm.
Cover Weight: 80 – 302 gsm.
Glue System: Hot-melt adhesive with large glue tank, two heated drums and side-glue wheels, plus notching and spine preparation up to 4 mm depth.
Book Clamps: 1.
Control System: Touch-screen control panel.
Electrical Requirements: Three-phase Y380-Y415 V or similar 50/60 Hz (Europe).
Dimensions (approx.): 2,790 mm (W) × 928 mm (D) × 1,343 mm (H).
Machine Weight: Approx. 695 kg.
Good working order.
Available immediately...
The Duplo DPB 500 is a fully automatic single-clamp perfect binding machine designed for high-quality softcover book production. Part of the Perfect Binder and Gatherer category, this 2007 model utilizes EVA hot-melt adhesive to deliver strong, consistent binding results ideal for short-to-medium production runs, digital print environments, and print-on-demand applications. Featuring automated setup, precise spine preparation, and efficient glue application, the DPB 500 ensures professional binding quality with minimal operator intervention. Widely used by commercial printers and book manufacturers, it excels in producing paperbacks, manuals, catalogues, and instructional materials with a maximum production speed of up to 525 books per hour.
Key Technical Aspects:
Dimensions and Specifications : The Duplo DPB 500 measures approximately 2,790 mm (W) × 928 mm (D) × 1,343 mm (H) and weighs around 695 kg. It operates on a three-phase electrical supply (Y380-Y415 V, 50/60 Hz) and features a touch-screen control panel for intuitive operation. The machine is equipped with a large glue tank, two heated drums, and side-glue wheels, along with notching and spine preparation up to 4 mm depth.
Paper Handling : The DPB 500 accommodates book thicknesses ranging from 1 mm to 51 mm (excluding cover) and supports book sizes from 120 mm × 120 mm (min.) to 360 mm × 320 mm (max. spine × fore-edge). Cover sizes range from 120 mm × 250 mm (min.) to 360 mm × 696 mm (max.), with cover weights between 80–302 gsm. The machine includes a single book clamp for secure binding.
| Model | Duplo-DPB 500 |
|---|---|
| Manufacturer | Duplo |
| Year | 2007 |
| Machine Availability | Immediately |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Ringwood, UK |
Duplo - DPB 500
