Windmoeller & Hoelscher - QMT 1309

Machine Description

By Windmoeller & Hoelscher QMT 1309 (Serial No. 16719), this Bag Machine is designed for efficient, mid-range paper bag production with integrated printing and lamination capability. The machine operates at speeds up to 60 metres per minute, producing bag widths from 70–240 mm and processing paper widths between 250–500 mm in weights ranging from 35–70 gsm. It features three printing units, supports roll diameters up to 1,000 mm, and offers print cylinder repeats of 200, 220, 260, and 310. Gusset sizes from 30–90 mm are available across selected bag widths (125–200 mm), providing flexibility for various retail and food-service applications..
The integrated lamination unit runs at up to 50 metres per minute and handles lighter paper grades from 26–32 gsm, with roll diameters up to 750 mm, enabling the production of laminated specialty bags where enhanced strength or moisture resistance is required..
.
Running Speed 60 metres per minute.
Minimum width bag size 70 mm.
Maximum width bag size 240 mm.
Minimum paper width 250 mm.
Maximum Paper width 500 mm.
Minimum Paper gsm 35 gsm.
Maximum Paper gsm 70 gsm.
Printing units 3.
Maximum Roll O/D 1,000 mm.
Print Cylinders 200, 220, 260, and 310 Repeats .
Gussett sizes 30 - 90 mm on the following width bags: 125, 160, 175, 200, mm wide bags..
.
Lamination unit Yes.
Running Speed 50 metres per minute.
Minimum width bag size 70 mm.
Maximum width bag size 240 mm.
Minimum paper width 250 mm.
Maximum Paper width 500 mm.
Minimum Paper gsm 26 gsm.
Maximum Paper gsm 32 gsm.
Maximum Roll O/D 750 mm...
