Kirk-Rudy - 497 A Plastic Card Attachment System

Machine Description

We are pleased to offer:.
Used Kirk-Rudy 497A Year 2005.
Specification.
Plastic Card Attachment System.
Save time and money with Kirk-Rudy’s all-new KR 497 Servo Attaching System. Attach small plastic cards as well as product up to 8.5” x 11” quickly and accurately to a wide variety of product. The KR 497’s high-vacuum transport table is ready to run in line with another machine or KR feed system. Vacuum belts carry product smoothly beneath the hot melt applicator and KR 497 Servo-Feeder. Base length and width options make it easy to create an attaching system matching your requirements. Designed to be flexible, the KR 497 applicator handles a wide variety of products and jobs. Run plastic cards, magnets as well as a variety of folded paper products and apply up to three pieces onto a single carrier. If needed, the standalone feeder is easily mounted onto another product transport or web press..
Vacuum belt system.
Variable speed DC motor.
Attaching Feeder:.
Servo drive.
Run multiple cards onto a single piece.
Easily placed on other machines.
Height and Position control knobs.
Pivots upward and away for jam clearance.
Extended hopper guides.
Production Rate: Maximum base speed - 400 ft/min.
Material Handling: Base: Stock size (W x L): Min. 7.62 x 12.7 cm or 3”x 5”, Max. 43.18 x 35.56 cm or 17” x 14”.
Stock thickness Min. Single sheet, Max. 15.748 mm or 0.62”.
Attaching Feeder: Stock size (W x L): Min. 5.38 x 5.38 cm or 2.12” x 2.12”, Max. 27.94 x 21.59 cm or 11” x 8.5”.
Stock thickness Min. Single sheet, Max. 1.52 mm or 0.06”.
Length: 182.88 cm or 72”.
Height: 152.4 cm or 60”.
Width: 114.3 cm or 45” not including hot melt.
Electrical Requirements:.
Base: 120 VAC, 15 amp, 1 Ø.
Attaching Head: 220 VAC, 10 amp, 1 Ø.
Hot Melt Glue: 120 VAC, 20 amp, 1 Ø (220 VAC, 10 amp, 1 Ø).
Good working order.
Available immediately.
