Heidelberg - Platen

Machine Description

We are pleased to offer:.
Used Heidelberg 13 x 18 platen.
Specification.
The Original Heidelberg 13″ × 18″ Platen Press, commonly known as the Heidelberg Windmill, is a robust and highly regarded letterpress machine produced between 1923 and 1985. Named for its iconic rotating gripper system, this press delivers exceptional precision and efficiency by automatically feeding, printing, and delivering sheets in a rhythmic, windmill-like motion. It is valued for its durability, ease of adjustment, and suitability for a wide range of applications, including printing, embossing, die-cutting, and foil stamping..
.
Sheet size – maximum: 13.375″ × 18.125″ (340 × 460 mm).
Sheet size – minimum: 3.5″ × 4″ (90 × 100 mm).
Inside chase dimensions: 12.625″ × 17.75″ (320 × 450 mm).
Maximum speed: Up to 4,000 impressions per hour.
Impressional strength: 60 tons.
Floor space required: Approx. 4′ 9″ × 6′ 6″ (145 × 200 cm).
Power consumption: 1.5 kW / 2.5 hp motor.
Net weight: Approx. 4,600 lb (2,090 kg).
Feeding system: Pneumatic air-suction and rotating gripper.
Inking system: Automatic multi-roller fountain and vortex inking.
Impression control: Adjustable via control dials.
Optional capabilities: Foil stamping, embossing, die‑cutting .
Good working order.
Available immediately.
.
