Machine Description
Configuration: Cylinder letterpress / die-cutting press..
Year: Unknown..
Max paper size: 54 x 72 cm (21 x 28 inches)..
Min paper size: approximately 11.5 x 16 cm..
Max printing size: approximately 51.5 x 69 cm..
Printing system: Automatic cylinder letterpress printing system with reciprocating bed and impression cylinder..
Inking system: Oscillating cylinder inking unit with multiple distribution rollers..
Form locking: Standard Heidelberg cylinder chase locking system..
Max speed: approximately 3,500–4,000 sheets / hour..
Feeder type: Automatic single-sheet feeder with mechanical gripper transport..
Delivery system: High pile delivery with continuous automatic sheet output..
Registration: High-precision mechanical grippers and side lays for accurate sheet alignment..
Substrate thickness: Thin paper up to heavy cardboard and carton stock..
Applications: Letterpress printing, die-cutting, creasing, embossing, perforating, numbering, and packaging production..
Drive system: Heavy-duty mechanical cylinder drive with flywheel transmission..
Control system: Electromechanical operator controls with manual pressure and ink adjustment..
Renovation work (2018): Complete cleaning, mechanical servicing, lubrication overhaul, repainting, and operational restoration for production use..
Machine dimensions (L x W x H): approximately 3.34 m x 1.96 m x 1.60 m..
Total weight: approximately 4,500–4,800 kg..
Power consumption: approximately 5.5 kW to 7 kW (three-phase industrial supply)....
The Heidelberg Cylinder S is a robust cylinder letterpress and die-cutting press designed for high-precision printing and finishing applications. Renowned for its durability and versatility, this machine excels in letterpress printing, die-cutting, creasing, embossing, perforating, and packaging production. Featuring an automatic cylinder letterpress system with a reciprocating bed and impression cylinder, it ensures consistent quality and efficiency. The machine's oscillating cylinder inking unit, high-precision mechanical grippers, and heavy-duty mechanical drive system make it ideal for handling a wide range of substrates, from thin paper to heavy cardboard. Restored in 2018, the Heidelberg Cylinder S combines classic engineering with modern reliability, offering exceptional performance for commercial and specialty printing operations.
Key Technical Aspects:
Dimensions and Specifications : The Heidelberg Cylinder S has a compact yet robust build, measuring approximately 3.34 m (L) x 1.96 m (W) x 1.60 m (H) and weighing between 4,500–4,800 kg. It operates on a three-phase industrial power supply with a consumption of approximately 5.5 kW to 7 kW. The machine underwent a complete renovation in 2018, including mechanical servicing, lubrication overhaul, and repainting, ensuring optimal performance and longevity.
Paper Handling : This press accommodates a maximum paper size of 54 x 72 cm (21 x 28 inches) and a minimum size of approximately 11.5 x 16 cm. It features an automatic single-sheet feeder with mechanical gripper transport and a high-pile delivery system for continuous sheet output. High-precision mechanical grippers and side lays ensure accurate sheet alignment, supporting substrates ranging from thin paper to heavy cardboard and carton stock.
Printing Unit : The Heidelberg Cylinder S employs an automatic cylinder letterpress printing system with a reciprocating bed and impression cylinder. It achieves a maximum printing size of approximately 51.5 x 69 cm and operates at speeds of 3,500–4,000 sheets per hour. The machine is equipped with a standard Heidelberg cylinder chase locking system for secure form mounting and is designed for versatile applications, including letterpress printing, die-cutting, and embossing.
Ink System : The press features an oscillating cylinder inking unit with multiple distribution rollers, ensuring consistent ink distribution and high-quality printing results. The system is designed for efficient ink transfer, supporting a wide range of printing applications with manual pressure and ink adjustments for precise control.
Plate Cylinder : The machine utilizes a standard Heidelberg cylinder chase locking system for secure plate mounting. This system ensures stable and accurate positioning of printing forms, contributing to the machine's high-precision registration and reliable performance across various printing and finishing tasks.
| Model | Heidelberg-Cylinder S |
|---|---|
| Manufacturer | Heidelberg |
| Machine Availability | Immediately |
| Machine Condition | In Stock |
| Price | 6000.00 EUR |
| Location | 103 Rue des Écoles, 38121 Reventin-Vaugris, France |
