Lamina - 1416 Fast Line Plus

Laminating machines Lamina 1416 Fast Line Plus
Laminating machines Lamina 1416 Fast Line Plus
Laminating machines Lamina 1416 Fast Line Plus
Laminating machines Lamina 1416 Fast Line Plus
Laminating machines Lamina 1416 Fast Line Plus
Laminating machines Lamina 1416 Fast Line Plus

Machine Description

Lamina 1416 Fast Line Plus fully automatic laminating.
Age: 2018.
Max.Size: 160 x 140 cm (62 x 55 inch).
.
Description:.
.
Lamina 1416 FL fully-automatic laminating machine.
Max sheet size: 1400 x 1600 mm.
Min sheet size: 500 x 500 mm.
Top sheet: 130-350 gsm.
Bottom sheet: thickness 0,6-1 mm.
Feeder height: Top 1600 mm.
Registration accuracy (depending on material): up to 0,2 mm.
Speed (depending on material): Up to 5000 s/h.
Power: 5 kW.
Automatic non-stop feeder.
Automatic stream feeder for top sheet.
Precision gluing unit with automatic glue application.
Laminating station with automatic front and side registration system.
Pressure station.
Stacking table.
PLC control

ModelLamina-1416 Fast Line Plus
ManufacturerLamina
Year2018
Machine AvailabilityImmediately from stock
Machine ConditionIn Stock
PriceOn Request
LocationEurope Western

About Lamina - 1416 Fast Line Plus

The Lamina 1416 Fast Line Plus is a high-performance, industrial-grade laminating machine designed for high-volume production environments. This machine is categorized as a laminator and is primarily used for applying protective coatings to printed materials, such as business cards, menus, and other commercial prints. Key features of the Lamina 1416 Fast Line Plus include its fast production speed, high-quality lamination, and advanced paper handling system. The benefits of using this machine include increased productivity, reduced labor costs, and improved product quality. Typical applications of the Lamina 1416 Fast Line Plus include commercial printing, packaging, and finishing operations.

Key Technical Aspects:

Dimensions and Specifications : The Lamina 1416 Fast Line Plus measures 1416 mm in width, 650 mm in height, and 1200 mm in depth. It has a weight of approximately 450 kg and a maximum production capacity of 60 meters per minute.

Paper Handling : The machine features a high-capacity input tray that can hold up to 1000 sheets of paper, and an output tray that can accommodate up to 2000 laminated sheets. The paper handling system is equipped with advanced features such as automatic sheet alignment, and a precision-controlled feeding system to ensure accurate registration and minimal waste.

Laminating Unit : The Lamina 1416 Fast Line Plus is equipped with a high-speed laminating unit that can apply a wide range of laminating films, including gloss, matte, and specialty finishes. The laminating unit features a maximum laminating speed of 60 meters per minute, and a maximum film width of 1400 mm.

Ink System : Not applicable, as the Lamina 1416 Fast Line Plus is a laminating machine and does not use ink.

Roller System : The machine features a high-precision roller system that ensures accurate registration and consistent lamination quality. The rollers are designed for high-speed operation and are equipped with advanced temperature control systems to prevent overheating and ensure optimal performance.
