Machine Description
We are pleased to offer:.
Used D&K Europe Jupiter B2 Thermal Laminating System Year 2008.
Specification.
Fully automated compact B2 Laminator.
PLC Controlled.
Compact footprint.
High pile feeder with pallet loading to maximise efficiency for longer run work.
Equally adept at running Litho or Digital output.
Pneumatically controlled scrolled in-feed roller to help feed lightweight/digitally printed sheets.
Heated Chrome top roller.
Pneumatically controlled Rubber nip roller.
De-curl bar which can be adjusted on the run.
Cantilevered Mandrel.
Film can be moved laterally on the run.
Film slitter for non-standard sizes.
Burster type sheet separator.
Jogger at delivery.
Maximum sheet size: 540mm x 760mm.
Minimum sheet size: 200mm x 200mm.
Speed: Up to 40m per minute.
Core size: 75mm (3”).
Pile height: 840mm.
Maximum recommended stock: Up to 600 gsm, 450 gsm for optimum results.
Minimum recommended stock: 115gs, (90gsm if re-wind available).
Heating: Sealed Oil Filled Roller.
Average power consumption: 5 kw.
Feeder: Yes.
Separator: Yes.
In-line slitting: Yes.
Dimensions: H – 1400mm W – 1200mm L – 1950mm.
Weight: 650kg.
Electrical requirements: 3 phase, 380v-415v, 7kw.
Air requirements: 15 cfm @ 100 psi dry air.
Manufactured in Poland.
Good working order.
Available immediately.
Read more: https://www.jerrycurtin.com/machine/en-134535/d-and-k-europe-jupiter-b-2-thermal-laminating-system...
The D & K Jupiter B 2 Thermal Laminating System is a fully automated, compact B2 laminator designed for high-efficiency thermal laminating applications. Part of the Laminating and coating category, this 2008 model offers precise, PLC-controlled operation with a compact footprint, making it ideal for both litho and digital output. Key features include a high pile feeder with pallet loading for extended production runs, pneumatically controlled rollers for handling lightweight or digitally printed sheets, and a heated chrome top roller for consistent laminating quality. Additional benefits include a de-curl bar, cantilevered mandrel, and in-line slitting for non-standard sizes. This system is well-suited for commercial printing, packaging, and finishing operations requiring reliable, high-speed laminating with minimal setup time.
Key Technical Aspects:
Dimensions and Specifications : The Jupiter B 2 Thermal Laminating System measures H – 1400mm, W – 1200mm, L – 1950mm, with a weight of 650kg. It operates at speeds up to 40 meters per minute and has an average power consumption of 5 kW. Electrical requirements are 3-phase, 380v-415v, 7kW, with air requirements of 15 cfm @ 100 psi dry air. The heating system features a sealed oil-filled roller for consistent thermal performance.
Paper Handling : This system accommodates a maximum sheet size of 540mm x 760mm and a minimum sheet size of 200mm x 200mm. It supports stock weights from 115 gsm (90 gsm with rewind) up to 600 gsm, with optimal results at 450 gsm. The high pile feeder allows a pile height of 840mm and includes pallet loading for extended production runs. Additional features include a pneumatically controlled scrolled in-feed roller, burster-type sheet separator, and jogger at delivery for precise handling of lightweight or digitally printed sheets.
| Model | D & K- Jupiter B 2 Thermal Laminating System |
|---|---|
| Manufacturer | D & K |
| Year | 2008 |
| Machine Availability | Immediately |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Ringwood, UK |
D & K - Jupiter B 2 Thermal Laminating System
