Polar - RAB 5

Key Technical Aspects:

Dimensions and Specifications : The Polar RAB 5 has a compact footprint of 1450 mm (57.1 in) in length, 1050 mm (41.3 in) in width, and 1400 mm (55.1 in) in height. It weighs approximately 1200 kg (2646 lbs) and has a maximum cutting capacity of 800 mm (31.5 in) in length and 550 mm (21.7 in) in width.

Paper Handling : The RAB 5 features a programmable back gauge with a range of 20-800 mm (0.8-31.5 in) and a repeat cut function for efficient cutting of multiple sheets. The machine is equipped with a large, adjustable clamping system that can handle sheets up to 550 mm (21.7 in) in width and 800 mm (31.5 in) in length.

Cutting Unit : The cutting unit is equipped with a high-precision, hardened steel knife that can cut up to 80 mm (3.2 in) of paper or cardboard at a time. The machine features a cutting speed of up to 45 cycles per minute and an accuracy of ±0.1 mm (0.004 in).

Safety Features : The RAB 5 is designed with operator safety in mind, featuring a two-hand operation system, safety light curtains, and an emergency stop function. The machine also includes a noise reduction system and a dust extraction system for a cleaner working environment.

Electrical Requirements : The Polar RAB 5 requires a three-phase power supply of 400V, 50Hz, and has a maximum power consumption of 3.5 kW (4.7 HP).
