Machine Description
We are pleased to offer:.
Used Miller Johannisberg Cylinder – Converted for Hot Foil Stamping.
Year 1970.
Specification.
We are pleased to offer this 1970 Miller Johannisberg Cylinder 730 × 1040 mm, professionally converted for hot foil stamping..
Originally manufactured as a high-quality cylinder press, this machine has been adapted to perform hot foil stamping applications, making it a robust and cost-effective solution for companies involved in print finishing, packaging, and speciality printing..
The cylinder construction ensures consistent pressure distribution and excellent registration accuracy, ideal for large-format foil stamping on a wide range of materials. Its heavy-duty German engineering provides long-term durability and stable performance in demanding production environments..
Type: Cylinder Press – Converted for Hot Foil Stamping.
Maximum Sheet Size: 730 x 1040 mm (some listings state 720 x 1040 mm).
Minimum Sheet Size: 297 x 420 mm.
Maximum Stamping Area: 710 x 1020 mm.
Substrate Thickness: 54 – 400 g/m² (approx. 0.1 – 0.5 mm).
Speed: Up to 3,000–3,500 impressions per hour (mechanical speed), with effective operating speeds depending on complexity.
Heated Bed: Usually 4 to 6 independent heat zones, temperature range 0–200°C.
Die Height: Set for 6.35 mm (standard), but often convertible to 7 mm.
Foil Feeding: Multiple independent foil pull rollers (usually 2 or 3) with precision stepper drives.
Max Foil Roll Diameter: 125 mm.
Maximum Foil Width: 1020 mm.
General Dimensions: Approx. 1,850mm(H) x 1,240mm(W) x 3,800mm(L).
Weight: Approximately 8,500 kg.
Power/Air: 3 Phase, 380/415V, 50/60 Hz, 32-36 Amps per phase; 5 bar (75psi) air supply.
Good working order.
Available immediately...
This used 1970 Miller Johannisberg Cylinder press, professionally converted for hot foil stamping, offers a robust and cost-effective solution for high-quality print finishing applications. Originally engineered as a premium cylinder press, this machine has been expertly adapted to deliver precise hot foil stamping with consistent pressure distribution and exceptional registration accuracy. Ideal for large-format foil stamping on diverse substrates, it combines German engineering durability with versatile performance, making it well-suited for packaging, specialty printing, and decorative applications. The converted press features independent heat zones, multiple foil pull rollers, and heavy-duty construction, ensuring reliable operation in demanding production environments.
Key Technical Aspects:
Dimensions and Specifications : The machine has a maximum sheet size of 730 × 1040 mm (with some listings stating 720 × 1040 mm) and a maximum stamping area of 710 × 1020 mm. It supports substrate thicknesses ranging from 54 to 400 g/m² (approximately 0.1 to 0.5 mm). The press operates at speeds up to 3,000–3,500 impressions per hour, with effective speeds dependent on job complexity. General dimensions are approximately 1,850 mm (H) × 1,240 mm (W) × 3,800 mm (L), with a weight of around 8,500 kg. It requires a 3-phase power supply (380/415V, 50/60 Hz, 32-36 Amps per phase) and a 5 bar (75 psi) air supply.
Paper Handling : The machine accommodates a minimum sheet size of 297 × 420 mm and handles substrates with thicknesses between 54 and 400 g/m². Its cylinder construction ensures consistent pressure distribution and precise registration for high-quality foil stamping.
Printing Unit : The converted press features a heated bed with 4 to 6 independent heat zones, offering a temperature range of 0–200°C. It includes multiple independent foil pull rollers (typically 2 or 3) with precision stepper drives, supporting a maximum foil roll diameter of 125 mm and a maximum foil width of 1020 mm. The die height is set for 6.35 mm (standard), with convertibility to 7 mm.
| Model | Miller Johannisberg- Cylinder – Converted |
|---|---|
| Manufacturer | Miller Johannisberg |
| Year | 1970 |
| Machine Availability | Immediately |
| Machine Condition | In Stock |
| Price | On Request |
| Location | 46 Christchurch Rd, Ringwood BH24 1DW, UK |
