Heidelberg - S-Cylinder with Gold Foil and 2 Pull System

Machine Description

We are pleased to offer:.
Used Original Heidelberg S-Cylinder (540 × 720 mm) with Gold Foil & 2 Pull Systems.
Specification.
The Heidelberg S-Cylinder (540 × 720 mm) is a heavy-duty, high-precision cylinder press originally designed for letterpress printing and widely used today for hot foil stamping, embossing, debossing and die-cutting applications..
.
Renowned for its robust engineering and long service life, the S-Cylinder is a reliable solution for commercial print finishing and specialist packaging production..
.
In this configuration, the machine is equipped with a gold foil cylinder and two foil pull systems, enabling efficient and precise hot foil stamping. The dual pull system allows accurate foil advance control, improving material efficiency and ensuring consistent, high-quality finishing across medium and large formats..
.
The 540 × 720 mm format offers excellent versatility for a wide range of substrates, including paper and board.Cutting and creasing cylinder..
.
Maximum sheet size: 540 x 720 mm / 21 1/4 X 28 3/8 in.
Minimum sheet size: Approximately 115 × 160 mm (depending on configuration).
Maximum mechanical speed: Up to approx. 3,500 sheets per hour (in standard operation).
Gripper margin: Approx. 8–10 mm.
Machine weight: Approx. 4,500–5,000 kg (depending on equipment fitted).
Gold foil stamping cylinder fitted.
Two foil pull systems for controlled foil advance .
Good working order.
Test possible.
Available immediately.
