Schneider Senator - 92 E-Line

Machine Description

We are pleased to offer:.
Used Schneider Senator 92 E-Line Year 2006.
Specification.
The Schneider Senator 92 E Line is a high-precision paper guillotine, designed for efficient, accurate and user-friendly cutting operationsBandBuilt in Germany, this model features a direct electromechanical knife drive for maximum reliability, a PCC control unit with intuitive operation, and a system for fast and automated knife changes from the front..
Its compact design allows installation in limited spaces, while operating with low energy consumption and minimal noiseBandWith advanced safety features and robust German engineering, the 92 E Line is ideally suited for commercial printing houses and finishing environments that require high productivity, precision, and long-lasting performance..
Cutting width: 920 mm.
Feed depth: 920 mm.
Clamp opening: 120 mm.
Table height: 900 mm.
Machine width (without side tables BN): 1.675 mm.
Machine width (including side tables BN): 1.835 mm.
Machine depth: 1.992 mm, height: 1.620 mm.
Front table depth: 657 mm.
Side table depth (BN): 471 mm / Width (BN): 436 mm.
Side table depth (LST 750): 750 mm / Width (LST 750): 750 mm.
Power required (main drive): MaxBand5,5 kW.
Weight net: 1.720 kW.
Clamp pressure: MinBand100 daN / MaxBand3.000 daN.
Knife thickness: 12 mm.
Smallest cut, automatically: With clamp cover plate: (60 mm) * 70 mm / without clamp cover plate: ** 30 mm.
Backgauge speed: 225 mm/s.
Static floor load: 605 daN/m².
Contact area load: ( /- 12 %) 2,1 daN/cm².
* optional: smallest cut 60 mm with narrow clamp cover plate (50 mm).
smallest cut 50 mm with extra narrow clamp cover plate (40 mm).
** manual: smallest cut reducible to 20 mm.
Made in Germany.
Good working order.
Available immediately
