Stahl - KD 78

Key Technical Aspects:

Dimensions and Specifications : The Stahl KD 78 has a machine length of 7,780 mm, a machine width of 1,450 mm, and a machine height of 1,800 mm. It weighs approximately 4,500 kg and has a maximum sheet size capacity of 780 x 1,070 mm.

Paper Handling : The KD 78 features a feeder with a capacity of up to 1,500 sheets, an intermediate stacker with a capacity of up to 1,000 sheets, and a delivery with a capacity of up to 1,500 sheets. The machine is equipped with a precision registration system, ensuring accurate sheet alignment and precise cutting.

Die-Cutting Unit : The die-cutting unit of the KD 78 is capable of operating at speeds of up to 8,000 sheets per hour, with a maximum cutting force of 400 tons. The machine features a precision cutting system with a cutting die gap of 0.5 mm to 5 mm, allowing for intricate cutting and creasing operations.

Ink System : Not applicable, as the KD 78 is a die-cutting machine and does not utilize an ink system.

Plate Cylinder : The KD 78 features a plate cylinder with a diameter of 220 mm, allowing for precise registration and accurate cutting of complex designs. The plate cylinder is designed for easy setup and changeover, reducing downtime and increasing overall productivity.
