Machine Description
OVERALL DIMENSIONS.
Length 1830mm.
Width 555mm.
Height 1185mm.
Weight 180kgs.
.
POWER REQUIREMENT - 1ph 220/240v.
.
MAXIMUM SPEED A4 S.P.H. - 1800.
.
MAXIMUM SHEET SIZE - Length 630mm - Width 330mm.
.
MINIMUM SHEET SIZE - Length 160mm Width 140mm.
.
MAXIMUM PAPER WEIGHT - 350gsm+.
.
MINIMUM PAPER WEIGHT - 90gsm.
.
MAXIMUM NUMBER OF CREASES PER SHEET - 9.
.
MAXIMUM NUMBER OF FOLDS PER SHEET - 2.
.
MAXIMUM NUMBER OF STORED PROGRAMMES - 6.
.
MINIMUM REPEAT CREASE DISTANCE - 4mm (depending on paper weight).
.
MINIMUM CREASE DISTANCE FROM LEADING EDGE - 25mm.
.
MINIMUM FOLD DISTANCE FROM LEADING EDGE - 25mm (depending on paper weight.
.
The Morgana Digifold - Creaser and Folder is one of our best selling folders. The Digifold has it all, accuracy, reliability and it is easy to use. By having both a creaser and folder in one, this machine would be an asset to any company. Contact us today to discuss this Morgana Digifold..
.
After the success of the AutoCreaser and the best-seller UFO Folder, Morgana came up with something entirely new. Thus presenting the DigiFold. Combining the traits of a creaser and folder into one, with added prestige and quality. .
.
Using a creasing automated creasing technology along with an electronically controlled flying knife contoured around extra large diameter rollers moving at the same peed as the material passing through the machine. The DigiFold boasts a dynamic sheet deflector that only comes in contact with the leading edge of the sheet. This allows multiple folds to be done without the risk of scratching or marking
| Model | Morgana-DigiFold |
|---|---|
| Manufacturer | Morgana |
| Machine Availability | Immediately from stock |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Lancaster, United Kingdom |
About Morgana - DigiFold
The Morgana DigiFold is a digital creasing and folding machine designed for high-volume production of folded documents, brochures, and other printed materials. This machine is ideal for commercial printers, in-plant printers, and digital print service providers who require a reliable and efficient solution for folding and creasing a wide range of paper stocks. The Morgana DigiFold offers advanced features, precision engineering, and exceptional performance, making it an excellent choice for businesses seeking to streamline their finishing operations and improve productivity.
Key Technical Aspects:
Dimensions and Specifications : The Morgana DigiFold measures 55.1 inches (1400 mm) in length, 29.5 inches (750 mm) in width, and 43.3 inches (1100 mm) in height, with a weight of approximately 1,102 pounds (500 kg). The machine has a maximum sheet size capacity of 13.39 inches x 19.69 inches (340 mm x 500 mm) and a minimum sheet size capacity of 5.51 inches x 7.87 inches (140 mm x 200 mm).
Paper Handling : The Morgana DigiFold features a high-capacity feed tray that can hold up to 2,000 sheets of paper, and an output tray that can accommodate up to 1,000 folded sheets. The machine is equipped with advanced paper handling capabilities, including automatic sheet detection, double-sheet detection, and anti-static devices to prevent paper jams and ensure smooth operation.
Folding Unit : The Morgana DigiFold is equipped with a high-speed folding unit that can produce up to 6,000 folded sheets per hour. The machine features a patented creasing system that ensures accurate and consistent creasing, and a precision folding mechanism that can handle a wide range of paper stocks and fold types.
Creasing Unit : The Morgana DigiFold features a high-precision creasing unit that uses a unique scoring system to create sharp, accurate creases in a wide range of paper stocks. The creasing unit is adjustable, allowing users to customize the crease depth and width to suit specific application requirements.
Control System : The Morgana DigiFold is equipped with an intuitive touchscreen control system that allows users to easily set up and operate the machine. The control system features a range of pre-programmed fold settings, as well as the ability to store custom fold settings for repeat jobs.
