Machine Description
We are pleased to offer:.
Used Horizon AFC 566 AKT Year 2012.
Specification.
High-performance, space-efficient automated cross-knife folding machines.
- The Horizon AFC-56 series features advanced automation, user-friendliness, and high-quality folding..
– Set up a wide variety of fold patterns by simply touching the corresponding icon and inputting the sheet size on the large LCD colour touchscreen. 17 fold patterns are set on AFC-566AKT..
– Automated setups take just a few seconds. The LCD touchscreen prompts the operator through all remaining settings for fast, efficient production. All adjustments are user-friendly and require minimal skill or training..
– Fold rollers are constructed with a combination of steel and soft polyurethane for superior grip and sharp, consistent folding..
– Horizon's advanced rotary suction feed system delivers fast, consistent feeding on a wide range of paper stocks..
Machine Structure: 6KTT (6 Buckles Fold Knife, 2 Buckles Below Knife).
Sheet Size Max. (Width x Length): 558 x 850 mm or 21.965” x 33.460” (Length 1,100 mm or 43.310” with optional extension table).
Sheet Size Min. (Width x Length): 128 x 148 mm or 5.040” x 5.830” (Register guide minimum set position: width 74 mm or 3.0”).
Sheet Weight Range: 35 to 220 gsm.
Belt Speed: 30 to 230 meters (99 to 754 feet) per minute.
Knife Fold 180 meters (590 feet) per minute.
Production Speed: Suction Head 42,000 cycles per hour, Knife 21,000 cycles per hour..
Good working order.
Available immediately.
Read more: https://www.jerrycurtin.com/machine/en-134463/horizon-afc-566-akt...
The Horizon AFC 566 AKT is a high-performance, space-efficient automated folding machine designed for precision and efficiency in commercial printing and finishing operations. Part of the acclaimed AFC-56 series, this model combines advanced automation with user-friendly operation, making it ideal for producing a wide variety of fold patterns with minimal setup time. Featuring a large LCD color touchscreen, the AFC 566 AKT allows operators to configure fold patterns quickly by selecting icons and inputting sheet dimensions, streamlining production workflows. Its robust construction, including steel and polyurethane fold rollers, ensures sharp, consistent folding across diverse paper stocks. The machine`s rotary suction feed system guarantees fast and reliable paper handling, while automated adjustments reduce the need for extensive operator training. Suitable for applications such as brochures, booklets, and marketing materials, the Horizon AFC 566 AKT delivers high-speed performance and versatility for mid to large-scale production environments.
Key Technical Aspects:
Dimensions and Specifications : The Horizon AFC 566 AKT, manufactured in 2012, features a 6KTT machine structure (6 Buckles Fold Knife, 2 Buckles Below Knife). It supports a maximum sheet size of 558 x 850 mm (21.965” x 33.460”) and a minimum sheet size of 128 x 148 mm (5.040” x 5.830”), with an optional extension table allowing a maximum length of 1,100 mm (43.310”). Production speeds reach up to 42,000 cycles per hour with the suction head and 21,000 cycles per hour with the knife fold system. Belt speed ranges from 30 to 230 meters (99 to 754 feet) per minute, while the knife fold operates at 180 meters (590 feet) per minute.
Paper Handling : The machine accommodates a sheet weight range of 35 to 220 gsm, ensuring compatibility with a broad spectrum of paper stocks. Horizon`s advanced rotary suction feed system enables fast, consistent feeding, while the automated setup process minimizes manual adjustments and reduces downtime. The machine supports 17 pre-configured fold patterns, allowing for quick transitions between different folding requirements.
| Model | Horizon-AFC 566 AKT |
|---|---|
| Manufacturer | Horizon |
| Year | 2012 |
| Machine Availability | Immediately |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Ringwood, UK |
Horizon - AFC 566 AKT
