Duplo - DF-1000

Key Technical Aspects:

Dimensions and Specifications : The Duplo DF-1000 measures 63.8 inches (162 cm) in length, 43.3 inches (110 cm) in width, and 55.1 inches (140 cm) in height, with a weight of approximately 1,323 pounds (600 kg). It has a maximum sheet size capacity of 13.39 inches x 19.69 inches (340 mm x 500 mm) and a minimum sheet size capacity of 5.51 inches x 7.87 inches (140 mm x 200 mm).

Paper Handling : The DF-1000 features a high-capacity feed tray that can hold up to 500 sheets, and a delivery tray that can accommodate up to 500 folded sheets. It is equipped with advanced paper handling capabilities, including sheet detection, skew correction, and jam detection, ensuring smooth and efficient folding operations.

Folding Unit : The Duplo DF-1000 is capable of producing up to 10,000 folded sheets per hour, with a maximum folding speed of 166 feet per minute (50.6 meters per minute). It offers six pre-programmed fold patterns, including letter fold, accordion fold, and gate fold, and can accommodate custom fold patterns.

Control System : The machine is equipped with a user-friendly control panel featuring a 7-inch color touchscreen display, allowing for easy operation and monitoring of the folding process. It also includes advanced features such as batch counting, sheet counting, and error detection.

Optional Features : The Duplo DF-1000 offers various optional features, including a scoring unit, a perforating unit, and a bleed trimmer, which can be added to enhance its functionality and versatility.
