Machine Description
We are pleased to offer:.
Used Petratto Folder Gluer METRO 78 - 105 Year 2007.
Specification.
No crash lock.
Nordson glue gun.
2 nozzles with 2 feeders continuous and standard.
*Diamond Shaped Bars.
These bars have a single locking point, and consequently setting times are reduced, and lower grammages can be processed..
Machine strength, accuracy and speed are improved..
*Low Bridges.
The new lower bridges allow a more user-friendly access to the machine..
Size changeovers are faster and tool cleaning is more accurate.
*Self-Aligning Transportation Wheels.
The new self-aligning transportation wheels help placing and moving the products..
Working speed is also increased..
*Hooks And Clamps.
Attachments are placed on the machine between bridges and clamps..
Hooks and clamps have different sizes thus providing strength and accuracy..
The movable bridges can be placed along the whole machine, thanks to a quick change of the hooking points..
*Side Lay.
The left or right-side lays can be placed both before or between the jobs, to obtain perfect quality when folding and gluing the product, even with low grammages..
With this lay is possible to have a perfect quality of folding and gluing process also with low grammage paper..
*SC10 Standard Single Delivery.
A simple and reliable way to collect products coming out of the folding gluing machine..
Easy and fast to set up..
With compact dimensions..
Delivery belt’s height is adjustable..
Max. Size: 780 x 780 mm (1050 x 780 mm).
Min. Size: 60 x 60 mm.
Paper weight: 90 – 600 g.
Max. Speed: 200 m/min.
Max. Production: 44000 c/h.
Machine Dimension: 5 x 1,2 m.
Good working order.
Available immediately.
Read more: https://www.jerrycurtin.com/machine/en-134498/petratto-metro-78-105...
The PETRATTO Metro 78-105 is a high-performance used folder gluer machine designed for precision folding and gluing operations in packaging production. Manufactured in 2007, this model excels in processing a wide range of paper weights and sizes with exceptional speed and accuracy. Key features include diamond-shaped bars for reduced setup times, self-aligning transportation wheels for improved mobility, and low bridges for easier access during size changeovers. The machine is equipped with a Nordson glue gun system, dual feeders, and adjustable side lays to ensure consistent quality even with low-grammage materials. Ideal for corrugated and carton packaging applications, the Metro 78-105 delivers reliable performance with a maximum speed of 200 m/min and production capacity of up to 44,000 cycles per hour.
Key Technical Aspects:
Dimensions and Specifications : The Metro 78-105 has a compact footprint of 5 x 1.2 meters and supports a maximum sheet size of 780 x 780 mm (extendable to 1050 x 780 mm) with a minimum size of 60 x 60 mm. It operates at a maximum speed of 200 meters per minute, achieving up to 44,000 cycles per hour. The machine includes a standard SC10 single delivery system with adjustable belt height for efficient product collection.
Paper Handling : The machine processes paper weights ranging from 90 to 600 gsm. It features diamond-shaped bars for improved strength and accuracy, low bridges for faster size changeovers, and self-aligning transportation wheels to enhance workflow efficiency. Hooks and clamps with adjustable positioning ensure secure handling of materials during folding and gluing operations.
| Model | PETRATTO-Metro 78-105 |
|---|---|
| Manufacturer | PETRATTO |
| Year | 2007 |
| Machine Availability | Immediately |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Ringwood, UK |
