FOCUS - eFlex 330-2 S

Machine Description

Full Servo Drive Technology.
.
EFLEX 330 – 2 S & helical gearing.
.
8 Colour + Extended Die Module.
.
2 x Die + Sheeter.
.
8 X Lamp IR & Hot Air Drying Systems.
.
8 x Lamp UV System + Chill Rolls & Chiller.
.
2nd Pass.
.
Upgrade – Unwind Roll Lift.
.
Corona - Single Sided (2 Kw).
.
Web Cleaner (2 Sided) with anti static.
.
Rail System.
.
Turn Bar with Delam-Relam (Rail mounted).
.
Cold Foil (Rail Mounted).
.
Sheet Stacker (Shingle Conveyor).
.
Peel & Reveal.
.
Tint roll with air mandrel.
.
Antistatic unit 4 bars.
.
Rotary die adaptors (1 Set).
.
Edge trim extraction (Venturi) - requires air supply.
.
Reverse rewind.
.
Video Inspection System (double side viewing E + L).
.
FOCUS Video Plate mounter Platemate.
.
Upgrade Full Length Rail.
.
Rail Mounted Snow Ball Waste Rewind.
.
Web width: 330 mm.
.
Minimum printing length: 180 mm.
.
Maximum printing length: 510 mm.
.
Material thickness: 18 microns to 280 g/m².
.
Pre-Register.
.
Autoregister.
.
Servo drive 2 per print head.
.
UNWIND MODULE: .
.
1000 mm diameter capacity.
.
high performance air core 76mm (Lug type leaves).
.
Servo braking system (closed loop).
.
automatic tension adjustment.
.
Automatic web guide.
.
splice guide with automatic paper clamps,.
.
Operator control panel.
.
End of Roll detection.
.
(Options to add corona treater, web cleaning systems).
.
INFEED ROLL: .
.
Servo drive with nip roll (closed loop tension control).
.
FLEXO PRINTING MODULES: .
.
HMI (touch screen operator interface).
.
28 D.P / 1/8” helical gearing.
.
Servo driven impression roll.
.
Independent servo driven anilox roll & print cylinder.
.
Pre-register set up functions..
.
Auto-register.
.
Cartridge based inking units.
.
Ink fountain tray with integral metering roll,.
.
doctor blades & side wipers..
.
On run lateral & linear register adjustment.
.
Automatic plate throw off & constant anilox rotation.
.
INFRA-RED: .
.
Individual Eco-control dryers with variable 0 - 2Kw infrared lamps and forced air over substrate,.
.
plus progressive temperature increase with press speed & waste air vacuum / extraction.
.
SLITTING UNIT .
.
2 x slitting unit - supplied with 5 x pneumatic crush slitters. (additional slitters optional).
.
ROTARY DIE / SHEETER MODULE: .
.
2 x Independent servo driven die station.
.
1 x Independent servo driven die / sheeter station.
.
Each die unit is independently driven & equipped with heavy duty anvil roll.
.
Removable anvil for reverse cutting applications.
.
Lateral & linear manual register adjustment..
.
WASTE REWIND TURRET: .
.
Servo driven rail mounted.
.
REWIND MODULE .
.
Direct torque motor drive.
.
Suitable for film to board products.
.
High performance air core.
.
Core 76mm (Lug type leaves).
.
Roll Break detection.
.
Inside or outside rolls option.
.
Maximum reel diameter: 800 mm.
.
HMI OPERATOR CONTROLS:.
.
MAIN PLC touch-screen Operator Control Interface,.
.
with predetermined count, press speed, Emergency Stop, Rewind tension adjustment..
.
Dryer controls, Pre-register, Data storage for job, materials, speeds, drying settings..
.
Diagnostics error display system for easy problem solving..
.
Focus remote service & support diagnosis.
.
