Esko - CDI Spark 2120

Key Technical Aspects:

Dimensions and Specifications :The Esko CDI Spark 2120 has a compact footprint, measuring 1340 mm (52.8 in) in width, 840 mm (33.1 in) in depth, and 1400 mm (55.1 in) in height. It weighs approximately 450 kg (992 lbs) and has a maximum power consumption of 2.5 kW. The machine is capable of handling plates up to 1200 mm (47.2 in) in length and 800 mm (31.5 in) in width.

Paper Handling :The CDI Spark 2120 features a vacuum-based plate handling system, which ensures precise plate registration and efficient production. The machine is equipped with a single plate input tray, capable of holding up to 50 plates, and a single output tray for processed plates.

Printing Unit :The Esko CDI Spark 2120 utilizes a high-resolution UV-LED imaging technology, offering a maximum resolution of 2540 dpi. The machine is capable of imaging plates at a speed of up to 12 square meters per hour (130 square feet per hour).

Ink System :The CDI Spark 2120 does not use ink, as it is a plate imager, not a printing press. Instead, it uses a UV-LED light source to cure the photopolymer on the flexographic plate.

Plate Cylinder :The plate cylinder on the Esko CDI Spark 2120 is designed for precise plate registration and efficient production. The cylinder is equipped with a vacuum system, ensuring accurate plate positioning during the imaging process.
