SPS - VITTESSA Star G2

Key Technical Aspects:

Dimensions and Specifications : The SPS VITTESSA Star G2 has a length of 6,300 mm, a width of 2,300 mm, and a height of 2,200 mm. It weighs approximately 12,000 kg and has a maximum sheet size capacity of 720 x 1,020 mm.

Paper Handling : The VITTESSA Star G2 features a high-capacity feeder with a maximum pile height of 1,200 mm, capable of handling paper weights from 60 to 400 gsm. The press is equipped with a dual-delivery system, allowing for simultaneous printing and delivery of sheets.

Printing Unit : The printing unit is equipped with eight printing units, each capable of producing up to 18,000 sheets per hour at a maximum print speed of 18,000 sph. The press features a maximum print resolution of 300 lpi and utilizes advanced, alcohol-free dampening and inking systems.

Ink System : The VITTESSA Star G2 uses a high-performance, oil-based ink system with a maximum ink capacity of 20 kg per unit. The press features an advanced, automated ink supply system, ensuring consistent and precise ink delivery.

Plate Cylinder : The plate cylinder has a diameter of 1,020 mm and is designed for precise, high-speed plate changing. The cylinder features a advanced, pneumatic clamping system, ensuring secure and consistent plate registration.
