Machine Description
We are pleased to offer:.
Used Matica Technologies S6200GE Card Issuance System Year 2017.
Specification.
Printer specifications.
Print technology: Monochrome thermal transfer and colour dye-sublimation, direct-to-card / Embossing, indenting / Tipping (black, silver, gold, white, blue and varnish).
Print resolution: 300 dpi.
Print area: Near edge-to-edge.
Speed: Up to 600 cph.
Embossing and indenting unit: Single 98 characters.
Printing: Single S1 high speed graphic printing unit with flip over and dual-side cleaning station.
Fonts: Standard Gothic and OCR7B emboss / OCRB1 and OCRB4 front indent/ OCRA1 and CVV2 rear indent/ Wide choice of country specific and other embossing/indent types.
Communications interface: USB 2.0, Ethernet.
Printer dimensions (LxWxH): 1930 to 3050 x 550 x 1400 mm (76 to 120’’ x 22’’ x 55’’).
Power supply: 220-240V/100-120V, 50-60 Hz.
Operating environment: Temperature: 15ºC - 30ºC, 59ºF - 86ºF/ Humidity: 30% - 70% (non-condensing).
.
Card specifications.
Input /output hopper capacity: 600 cards / 600 cards (Approx. 385 embossed cards).
Reject hopper capacity: 30 cards.
Card types: ABS, PET, PVC.
Software Maticard Pro: Windows® (32/64bit) 7, 8.1, 10, 11, Server 2012, 2016, 2019, 2022..
Diagnostic and setup software included.
Smart card SDK optional.
Encoding Magnetic stripe: Tracks 1, 2 & 3 ISO7811, HiCo/LoCo.
Contact / Contactless: EMV compliant contact chip encoding / EMV compliant contactless chip encoding..
.
Consumables.
Printer ribbons: Black monochrome ribbon: up to 11,200 prints per roll (45 mm length per card) 5-panel YMCKO colour ribbon: 1,000 prints per roll.
6-panel YMCKOK colour ribbon: 800 prints per roll.
Half-panel YMCKO colour ribbon (especially for photo): 1,400 prints per roll * Other monochrome ribbons available on request.
Tipping ribbon: Up to 4,000 prints per roll.
Colour tipping: Black, silver, gold, white, blue and varnish.
Rear infill ribbon (7 ch/card): Up to 4,500 prints per roll.
Front infill ribbon (35 ch/card): Up to 1,800 prints per roll.
Colour infill: black and white.
Good working order.
Available immediately.
.
Read More:.
https://www.jerrycurtin.com/machine/en-134421/matica-technologies-s-6200-ge-card-issuance-system...
The Matica Technologies S 6200 GE Card Issuance System is a high-performance digital press designed for secure and efficient card personalization and issuance. Operating in the Digital Press category, this 2017 model combines monochrome thermal transfer and color dye-sublimation printing with advanced embossing, indenting, and tipping capabilities. Ideal for financial institutions, government agencies, and corporate ID programs, the system delivers high-volume card production with exceptional precision. Key features include dual-side printing, EMV-compliant encoding, and versatile card material compatibility, ensuring reliable performance for credit cards, ID badges, access cards, and loyalty programs.
Key Technical Aspects:
Dimensions and Specifications : The S 6200 GE Card Issuance System measures 1930 to 3050 mm (L) x 550 mm (W) x 1400 mm (H) and operates on 220-240V/100-120V, 50-60 Hz power supply. It supports an operating environment of 15°C - 30°C (59°F - 86°F) with 30% - 70% non-condensing humidity. Communication interfaces include USB 2.0 and Ethernet, with software compatibility for Windows 7, 8.1, 10, 11, and Server 2012-2022 (32/64-bit).
Paper Handling : The system features input/output hoppers with a capacity of 600 cards each (approximately 385 embossed cards) and a reject hopper for 30 cards. It supports ABS, PET, and PVC card types, enabling versatile card production for various applications.
Printing Unit : The printer utilizes monochrome thermal transfer and color dye-sublimation technology with near edge-to-edge printing at 300 dpi resolution. It achieves speeds up to 600 cards per hour and includes a single 98-character embossing and indenting unit. The system supports standard Gothic and OCR7B embossing fonts, along with OCRB1, OCRB4, OCRA1, and CVV2 indenting options. A high-speed graphic printing unit with flip-over and dual-side cleaning station ensures consistent quality.
Ink System : The S 6200 GE uses specialized ribbons for various printing needs: black monochrome ribbon (up to 11,200 prints per roll), 5-panel YMCKO color ribbon (1,000 prints per roll), 6-panel YMCKOK color ribbon (800 prints per roll), and half-panel YMCKO ribbon (1,400 prints per roll). Tipping ribbons support up to 4,000 prints per roll in black, silver, gold, white, blue, and varnish. Rear infill ribbon (7 characters/card) yields up to 4,500 prints, while front infill ribbon (35 characters/card) provides up to 1,800 prints in black and white.
| Model | Matica Technologies- S 6200 GE Card Issuance System |
|---|---|
| Manufacturer | Matica Technologies |
| Year | 2017 |
| Machine Availability | Immediately |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Ringwood, UK |
Matica Technologies - S 6200 GE Card Issuance System
