Machine Description
System Specifications.
five color with white and varnish.
Print/Copy Process.
4-drum and 5-drum dry electrostatic transfer system with internal transfer belt.
.
Fusing.
Oil-less belt fusing method.
.
System Memory.
E-43A: 2GB x 2.
E-83A: 2GB x 8.
.
CPU.
E-43A: Intel i5-4570 (2.9GHz up to 3.6GHz with Turbo).
E-83A: Intel Xeon (Quad-Core) Xeon E5-2637 (3.5GHz up to 3.8GHz w/Turbo).
.
Interface.
Windows 7 Professional for Embedded Systems x64.
.
Document Feeder Type.
220-Sheet ADF with single-pass color duplex scanning at up to 220 ipm.
.
Control Panel.
Full-color 9" WVGA touch panel.
.
Copy Resolution.
600 dpi.
.
Print Resolution.
1200 x 4800 dpi VCSEL.
.
Scan Resolution.
600 dpi.
.
Simplex: 120 ipm; Duplex: 220 ipm.
.
Max Printable Area.
12.7" x 18.9" (323mm x 480mm).
12.7" x 27.2" (323mm x 692mm) (when using Oversize Sheet Tray Option).
.
Output Speed.
Full Color and Monochrome.
Thick1 (52.3 g/m2) - Thick7 (300 g/m2):80 ppm.
Thick8 (300.1 g/m2) - (360 g/m2): 65 ppm.
FC + 5ST (White).
Thick2 (63.1 g/m2) - Thick3 (105 g/m2):37.5 ppm.
Thick4 (105.1 g/m2) - Thick7 (300 g/m2):80 ppm.
Thick8 (300.1 g/m2) - (360 g/m2): 65 ppm.
5ST Only (White).
Thick2 (63.1 g/m2) - Thick7 (300 g/m2):80 ppm.
Thick8 (300.1 g/m2) - (360 g/m2): 65 ppm.
FC + 5ST (Clear).
Thick2 (63.1 g/m2) - Thick8 (360 g/m2):37.5 ppm in Quality Mode (default).
5ST Only (Clear).
Thick2 (63.1 g/m2) - Thick8 (360 g/m2):37.5 ppm in Quality Mode (default).
.
Paper Capacity.
Standard: 1st Tray: 1,000 sheets x 2 (Tandem), 2nd Tray: 500 sheets.
Optional: 3rd Tray: 1,000 sheets, 4th Tray: 2,000 sheets, 5th Tray: 1,000 sheets (RT5090).
Optional: 3rd-8th Tray: 2,200 sheets each (RT5100).
Bypass Tray: 500 sheets.
.
13" x 19.2"/13" x 27.5".
.
Paper Weight.
1st Tray: 14 lb. Bond - 110 lb. Cover (52.3 - 300 g/m2); Plain Paper, Recycle Paper, Preprinted, Letterhead, Pre-punched.
2nd Tray: 14 lb. Bond - 95 lb. Cover (52.3 - 256 g/m2); Plain Paper, Recycle Paper, Preprinted Paper, Letterhead, Prepunched Paper, Tab Stock.
3rd Tray (RT5090): 14 lb. Bond - 95 lb. Cover (52.3 - 256 g/m2); Plain Paper, Recycle Paper, Preprinted Paper, Letterhead, Pre-punched Paper, Tab Stock, Glossy/Matte Paper, OHP (Transparency), Translucent Paper, Envelopes, Textured Paper.
4th Tray (RT5090): 14 lb. Bond - 110 lb. Cover (52.3 - 300 g/m2).
5th Tray (RT5090): 14 lb. Bond - 95 lb. Cover (52.3 - 256 g/m2).
3rd-8th Tray (RT5100): 14 lb. Bond - 130 lb. Cover (52.3 - 300 g/m2) Plain Paper, Recycle Paper, Preprinted Paper, Letterhead, Pre-punched Paper, Tab Stock, Glossy/Matte Paper, Translucent Paper, Envelopes, Textured Paper, Colored Paper, Clear Media.
Vacuum Feed Oversize Tray: 14 lb. Bond - 110 lb. Cover (52.3 - 300 g/m2) coated.
RT5010 Bypass Tray: 14 lb. Bond - 81 lb.Cover (52.3 - 216 g/m2) uncoated.
Duplex: 14 lb. Bond - 130 lb. Cover (52.3 - 360 g/m2).
.
Max Monthly Volume.
240K.
.
Duty Cycle.
700K.
.
Power Requirements.
208-240V, 16A, 50/60Hz (2 Dedicated Power Cords).
.
Maximum Power Consumption.
5,000 W.
.
Dimensions W x D x H.
Pro C7100/Pro C7100X: 51.9" x 35.8" x 47.9" (1320mm x 910mm x 1218mm).
.
Weight.
Pro C7100/Pro C7100X: Less than 1,276 lbs. (580 kg).
| Model | Heidelberg-Pro C7100X |
|---|---|
| Manufacturer | Heidelberg |
| Year | 2016 |
| Machine Availability | Immediately from stock |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Netherlands |
About Heidelberg - Pro C7100X
The Heidelberg Pro C7100X is a high-performance, commercial-grade digital printing press designed for demanding print environments. This cutting-edge machine falls under the category of digital printing presses, specifically tailored for high-volume production of premium-quality prints. Key features of the Pro C7100X include its exceptional print speed, high-resolution output, and advanced paper handling capabilities. The benefits of this machine include increased productivity, reduced turnaround times, and unparalleled print quality. Typical applications of the Heidelberg Pro C7100X include commercial printing, publishing, and high-end graphic arts.
Key Technical Aspects:
Dimensions and Specifications : The Heidelberg Pro C7100X measures 13,780 mm in length, 2,440 mm in width, and 1,900 mm in height, with a weight of approximately 4,500 kg. The machine has a maximum sheet size capacity of 330 x 660 mm and a minimum sheet size capacity of 210 x 297 mm.
Paper Handling : The Pro C7100X features a high-capacity paper handling system, comprising a 5,000-sheet input tray and a 3,000-sheet output tray. The machine is capable of handling a wide range of paper weights, from 70 to 350 gsm, and supports various paper types, including coated and uncoated stocks.
Printing Unit : The Heidelberg Pro C7100X boasts a high-speed printing unit, capable of producing up to 100 pages per minute in color and 120 pages per minute in monochrome. The machine features a maximum print resolution of 1,200 x 3,600 dpi, utilizing Heidelberg's proprietary toner technology.
Ink System : The Pro C7100X employs a dry toner ink system, with a capacity of up to 20,000 pages per color. The machine features an advanced toner management system, ensuring consistent and precise color reproduction.
Plate Cylinder : The Heidelberg Pro C7100X does not utilize a traditional plate cylinder, as it is a digital printing press. Instead, the machine employs a high-resolution imaging system, which directly transfers the print image onto the printing drum, eliminating the need for physical printing plates.
