Yawa - TYM TDS

Machine Description

We are pleased to offer:.
Yawa 1050 TYM / TDS 750 × 1050 Automatic Die Cutter with Foiling Year 2016.
Specification.
The 2016 Yawa 1050 TYM / TDS 1050 is a heavy-duty automatic flatbed die-cutting and hot foil stamping machine, designed for high-volume commercial print finishing and packaging production..
.
This model combines powerful die-cutting performance with integrated hot foil stamping in a single pass, making it ideal for manufacturers requiring precision cutting together with premium decorative finishes..
.
Equipped with a 300-tonne pressure capacity, three foil pull systems, and 12 independently controlled heating zones, the machine delivers consistent foil transfer and accurate die cutting across medium and large formats..
.
The inclusion of non-stop feeder and non-stop delivery systems ensures continuous production, reducing downtime during pallet changes and increasing overall productivity..
.
This configuration is particularly suitable for folding carton production, luxury packaging, and high-end printed materials..
.
Maximum sheet size: 750 × 1050 mm.
.
Minimum sheet size: approx. 360 × 400 mm (depending on application).
.
Maximum die-cutting area: approx. 1040 × 730 mm.
.
Suitable for paper, solid board and corrugated board (up to approx. 4 mm thickness, depending on material).
.
Maximum mechanical speed: up to approx. 7,500 sheets per hour.
.
Foil stamping speed: up to approx. 6,500 sheets per hour (depending on job complexity).
.
Maximum cutting pressure: 300 tonnes.
.
Three longitudinal foil pull systems.
.
Programmable foil advance control.
.
12 heating zones for precise temperature distribution.
.
Compatible with metallic, pigment and holographic foils.
.
Non-stop feeder for continuous sheet loading.
.
Non-stop delivery for uninterrupted stacking.
.
High-capacity pile loading and delivery systems.
.
Precision gripper bar transport for stable sheet control.
.
-Heavy-duty steel frame construction.
.
-Flatbed die-cutting system with closed chase.
.
-PLC control with touchscreen interface.
.
-Automatic lubrication system (where fitted).
.
-Safety guarding compliant with industrial standards.
.
Typical Applications:.
.
Folding carton die cutting.
.
Luxury packaging with hot foil stamping.
.
Premium printed materials (invitations, covers, presentation folders).
.
Decorative metallic and holographic foil finishing.
.
Combined die cutting and foil stamping production in a single pass.
.
Good working order.
.
Available immediately...
