Heidelberg - SB 540 x 770 mm Cutting & Creasing Cylinder with Ink Units

Machine Description

We are pleased to offer:.
Used Heidelberg SB 540 x 770 mm Cutting & Creasing Cylinder with Ink Units.
Specification.
The Heidelberg SB Cylinder is a classic industrial cylinder press converted for cutting and creasing, widely used in the production of folding cartons, packaging, labels, and commercial sheets of cardboard and paper. It is a robust machine designed for long periods of continuous operation, capable of handling large-format sheets, with solid mechanical control and integrated inking units, allowing combined or traditional pre-print operations..
.
This machine was originally produced between the 1950s and 1970s and is still sought after by workshops that value durability, low operating cost, and ease of maintenance..
.
Primary Use: Cutting & creasing (die cutting).
Maximum Sheet Size: 540 mm × 770 mm.
Minimum Sheet Size: 115 mm × 160 mm.
Maximum Production Speed: ~3,500 sheets per hour (up to 4,500 sheets depending on configuration).
Material Handling: Paper, light/medium cardboard, thin corrugated board.
Ink Units: Integrated (for partial printing or prepress control).
Gripper Margin: ~8–10 mm.
Net Weight: ~4,750 kg.
Dimensions (approx.): L 3,500 mm × W 2,000 mm × H 1,850 mm.
Power Requirements: Three-phase 415 V, 6–8 kW (may vary).
Good working order.
Available immediately...
