Machine Description
Feeder Unit:.
.
Lead-edge feeding system with vacuum suction for stable board transfer..
.
Anti-static dust removal system for a clean printing surface..
.
Optional: Servo-drive non-crush feeder for premium board handling..
.
Printing Unit:.
.
5 Color top-printing with vacuum wheel transfer..
.
Quick-lock plate mounting system for fast job changeover..
.
Chamber doctor blade inking system with auto-wash function..
.
Auto-register reset after plate cleaning..
.
Integrated drying unit for quick ink curing..
.
Slotting & Creasing:.
.
Precision slotting with lead-screw-driven accuracy..
.
Double-crease slotter knives for multi-ply boards..
.
Optional: Independent creasing unit for complex jobs..
.
Die-Cutting:.
.
Motor-driven anvil cover cylinder with 50 mm oscillation for even wear..
.
Anvil trimming device ensures smooth, flat surface finish..
.
Quick-change die mounting system..
.
Coater + Dryer:.
.
Inline water-based coating system for added protection & finish..
.
High-efficiency hot air/infrared dryer for rapid drying & productivity..
.
Folding & Gluing (if integrated):.
.
Vacuum suction belt transfer with non-crush wheels..
.
Spring-loaded plastic guide wheels for consistent folding accuracy..
.
Counter Ejector (if equipped):.
.
Servo-driven bundle collection system with pressing for stable stacks..
.
High-speed bundle delivery (up to 25 bundles/minute)....
The Dong Fang Topra GD1224 (5 Colour) is a high-performance die cutting machine designed for precision corrugated board processing in industrial packaging production. This advanced 5-color top-printing system integrates vacuum wheel transfer, quick-lock plate mounting, and automated ink management to deliver superior print quality, operational efficiency, and rapid job changeovers. Key features include a motor-driven anvil cover cylinder with oscillation for even wear, inline water-based coating with high-efficiency drying, and optional servo-driven non-crush feeding for premium board handling. Ideal for packaging manufacturers, commercial printers, and converters, the Topra GD1224 excels in producing high-quality corrugated boxes, displays, and specialty packaging with exceptional accuracy and productivity.
Key Technical Aspects:
Paper Handling : Lead-edge feeding system with vacuum suction ensures stable board transfer. Features an anti-static dust removal system for a clean printing surface. Optional servo-drive non-crush feeder available for premium board handling. Vacuum suction belt transfer with non-crush wheels in folding and gluing sections maintains consistent material flow.
Printing Unit : 5-color top-printing system with vacuum wheel transfer for precise registration. Quick-lock plate mounting enables fast job changeovers. Integrated drying unit supports rapid ink curing. Optional independent creasing unit for complex jobs. Servo-driven bundle collection system (if equipped) delivers up to 25 bundles per minute with pressing for stable stacks.
Ink System : Chamber doctor blade inking system with automatic wash function for efficient ink management. Auto-register reset after plate cleaning ensures consistent print alignment.
| Model | Dong Fang-Topra GD1224 (5 Colour) |
|---|---|
| Manufacturer | Dong Fang |
| Machine Availability | Immediately |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Shanghai, China |
Dong Fang - Topra GD1224 (5 Colour)
