Manroland - ROTOMAN

Commercial / Heatset Manroland  ROTOMAN
Commercial / Heatset Manroland  ROTOMAN
Commercial / Heatset Manroland  ROTOMAN
Commercial / Heatset Manroland  ROTOMAN
Commercial / Heatset Manroland  ROTOMAN

Machine Description

Cut-off: 620 mm.
Web-Width max.: 965 mm.
Web-Width min.: 450 mm.
Roll Diameter: 1271 mm.
Production Speed: 50.000 rev./h.
Wed-direction: left to right.
Configuration: 1 MEGTEC Splicer DLP2-50 autom. splicer - .
1 MAN Infeed Unit with E&L web guide control.
4 MAN Double Printing Units.
Press-Manager Terminal with printer.
HYDROMIX alcohol film Dampening.
TECHNOTRANS Refrige ration delta.d 200W.
BALDWIN/IMPACT Blanket Washing Device.
PPL Semi automatic plate changer.
Refrigertion Unit for Dampening.
TECHNOTRANS Ink Supply and leveling.
1 MAN Web catcher.
1 MEGTEC Dual Dry TNV 91.
1 MAN Chill Unit with four Chill rollers.
1 WEKO Silicon applicator WFG 1.4.
1 PLANATOL COMBIJET 8 MOD Gluing.
1 MAN-PECOM Video-System cut-off register.
1 MAN PECOM Video- System color register.
1 E&L Web guide Control.
1 MAN Folder Superstructur.
1 Former Fold - 3 Angle bars - Perforation and Slitting shafts.
1 MAN Folder PFI-16-1 System 2:3:3:3.
DELTA and Double parallel fold ( folded Size A/3 - A/4 - A/5 - long/Din 6.
1 BECKER SV 2.400 Blast Air Generator with air cooler

ModelManroland- ROTOMAN
ManufacturerManroland
Year2004
Machine AvailabilityImmediately
Machine ConditionExcellent
PriceOn Request
LocationEuropa

About Manroland - ROTOMAN

The Manroland ROTOMAN is a high-performance web offset printing press designed for large-scale commercial printing applications. This machine is categorized as a sheet-fed offset press, ideal for printing high-volume orders of brochures, catalogs, magazines, and newspapers. Key features of the ROTOMAN include its high-speed printing capabilities, advanced paper handling system, and precise registration control. The benefits of using this machine include increased productivity, reduced waste, and exceptional print quality. Typical applications of the ROTOMAN include commercial printing, publication printing, and packaging printing.

Key Technical Aspects:

Dimensions and Specifications : The Manroland ROTOMAN has a length of 23.6 meters (77.6 feet), a width of 2.5 meters (8.2 feet), and a height of 2.2 meters (7.2 feet). The machine weighs approximately 25 tons and has a maximum web width of 1,400 mm (55.1 inches). The ROTOMAN has a maximum printing speed of 80,000 impressions per hour.

Paper Handling : The ROTOMAN features a advanced paper handling system with a maximum web tension of 1,500 N (337 lbf). The machine is equipped with a splicer for automatic reel change, a web guide system, and a rewind unit with a maximum diameter of 1,200 mm (47.2 inches). The input tray has a capacity of 10,000 sheets, and the output tray has a capacity of 20,000 sheets.

Printing Unit : The ROTOMAN features a high-speed printing unit with a maximum printing speed of 80,000 impressions per hour. The machine uses a 3-form-4-high printing configuration and has a maximum printing width of 1,400 mm (55.1 inches). The printing unit is equipped with a remote inking system and a automatic plate changing system.

Ink System : The ROTOMAN uses a high-pigment, low-viscosity ink system with a maximum ink flow rate of 1,200 kg/h (2,646 lb/h). The machine is equipped with a automatic ink supply system and a ink temperature control system.

Plate Cylinder : The ROTOMAN features a plate cylinder with a diameter of 1,200 mm (47.2 inches) and a circumference of 3,770 mm (148.4 inches). The plate cylinder is equipped with a automatic plate changing system and a plate cleaning system.
