Machine Description
We are pleased to offer:.
Used Horizon MC-80a MC-80m (Collating Towers) FC-20 (Fore-edge Trimmer) SPF-20 (Stitcher & Folder) Booklet Maker Year 2003.
Specification.
Multi – Modular Air – Suction Collator.
MC-80a (Main Module).
MC-80m (Extension Module).
Number of Bins: 8.
Sheet Size: 148 x 210 mm to 318 x 470 mm (5.8” x 8.3” to 12.5” x 18.5”).
Bin Pile Height: 50 mm (2”).
Stock Weight: 52 gsm to 260 gsm.
Collating Speed (A4): 3,500 Sets/Hr.
Error Detection: Miss, Double, and Jam Detection system (Photocell).
Error Monitor: Two sets of Feed Error Monitors.
Power: 200 V 50/60Hz,220 V 60 Hz, 400 V 50 Hz.
Power Consumption: 200 V MC 80a 1,900 W, 400 V MC 80a 1,800 W / 200 V MC 80m 200 W, 400 V 200 W.
Machine Weight: MC 80a 229kg (505 lb) / MC 80m 223kg (492 lb).
.
SPF-20 Stitcher & Folder.
.
Sheet Size: Max. 350(W) x 500(L) mm (13.7" x 19.6") Min. 120(W) x 180(L) mm (4.8" x 7.1").
Finish Size: Max. 250(W) x 350(L) mm (9.8" x 13.7") Min. 90(W) x 120(L) mm (3.6" x 4.8").
Stitching Thickness: Max. 4 mm (0.15") (only for side stitch).
Stitching & Folding Thickness: Max. 2 mm (0.07") 20 sheets of 60 gsm.
Stitch Distance: 73 to 160 mm (2.9" to 6.2") Adjustable.
Stitching Wire: Standard: No. 25 (0.5 mm) (0.020") Option: No. 28 (0.4 mm) (0.016").
Production Speed: Max. 3,660 booklets/hr. (A4-Finish) Max. 4,050 booklets/hr. (A5-Finish).
Voltage / Frequency: Single Phase 200 V, 50 / 60 Hz Single Phase 220 V, 60 Hz Single Phase 230 V, 50 / 60 Hz.
Rated Current: Single Phase 200 V, 50 / 60 Hz, 3.7 / 2.9 A Single Phase 220 V, 60 Hz, 3.4 A Single Phase 230 V, 50 / 60 Hz, 2.2 / 2.0 A.
Power Consumption: Single Phase 200 V, 50 / 60 Hz, 460 / 400 W Single Phase 220 V, 60 Hz, 600 W Single Phase 230 V, 50 / 60 Hz, 520 / 500 W.
Heat Output: 620 kJ (150 kcal).
Motors: 200 W x 1, 100 W x 1, 60 W x 1, 15 W x 1.
Machine Weight: 1, 100 W x 1, 60 W x 1, 15 W x 1 470 kg (1,036.4 lbs.).
.
FC-20 Fore-edge Trimmer.
.
Book Size (Before Trim): Max. 250(W) x 350(L) mm (9.8" x 13.7") Min. 90(W) x 120(L) mm (3.6" x 4.8").
Finish Size: Max. 250(W) x 350(L) mm (9.8" x 13.7") Min. 85(W) x 120(L) mm (3.4" x 4.8").
Trimming Length: Max. 20 mm (0.78").
Trimming Thickness: Max. 4 mm (0.15") 50 sheets of 60 gsm.
Production Speed: 3,660 booklets/hr. (A4-Finish) 4,050 booklets/hr. (A5-Finish).
Voltage / Frequency: Single Phase 200 V, 50 / 60 Hz Single Phase 220 V, 50 / 60 Hz Single Phase 230 V, 50 / 50 Hz.
Rated Current: Single Phase 200 V, 50 / 60 Hz, 1.5 / 1.6 A Single Phase 220 V, 50 / 60 Hz, 1.4 / 1.0 A Single Phase 230 V, 50 / 60 Hz, 1.3 / 1.4 A.
Power Consumption: Single Phase 200 V, 50 / 60 Hz, 290 W Single Phase 220 V, 50 / 60 Hz, 280 / 220 W Single Phase 230 V, 50 / 60 Hz, 270 / 300 W.
Motors: 400 W x 1, 60 W x 1, 25 W x 1.
Machine Weight: 230 kg (507.2 lbs.).
Good working order.
Available immediately.
Read more: https://www.jerrycurtin.com/machine/en-134466/horizon-mc-80-a,-mc-80-m,-spf-20,-fc-20-booklet-maker...
This used Horizon MC-80a booklet production system is a high-performance, multi-modular collator and booklet maker designed for efficient collating, stitching, folding, and trimming of booklets and brochures. Combining the MC-80a main collating module, MC-80m extension module, SPF-20 stitcher & folder, and FC-20 fore-edge trimmer, this 2003 model offers a complete solution for producing professional-quality booklets with precision and reliability. Ideal for print shops, in-plant operations, and commercial printers, the system delivers consistent results with advanced error detection, adjustable stitching, and high-speed production capabilities. Its modular design allows for flexible configuration to meet varying production demands, making it a versatile choice for medium to high-volume booklet production.
Key Technical Aspects:
Dimensions and Specifications : The Horizon MC-80a system comprises multiple modules: MC-80a (main collator, 229kg/505 lb), MC-80m (extension module, 223kg/492 lb), SPF-20 stitcher & folder (470kg/1,036.4 lbs), and FC-20 fore-edge trimmer (230kg/507.2 lbs). The collator operates at 3,500 sets/hour (A4) with power consumption of 1,900W (200V) or 1,800W (400V). The SPF-20 achieves speeds up to 4,050 booklets/hour (A5) with a 4mm max stitching thickness, while the FC-20 trims up to 20mm with a 4mm max thickness. Voltage compatibility includes 200V, 220V, and 400V at 50/60Hz.
Paper Handling : The MC-80a collator supports sheet sizes from 148 x 210mm to 318 x 470mm (5.8” x 8.3” to 12.5” x 18.5”) with a bin pile height of 50mm (2”) and stock weight range of 52–260 gsm. The SPF-20 handles sheets from 120 x 180mm to 350 x 500mm (4.8” x 7.1” to 13.7” x 19.6”) and finishes booklets from 90 x 120mm to 250 x 350mm (3.6” x 4.8” to 9.8” x 13.7”). The FC-20 trims booklets from 90 x 120mm to 250 x 350mm (3.6” x 4.8” to 9.8” x 13.7”) with a max trimming length of 20mm.
| Model | Horizon-MC-80a |
|---|---|
| Manufacturer | Horizon |
| Year | 2003 |
| Machine Availability | Immediately |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Ringwood, UK |
