Machine Description
Duplo 4000 Collator + Bookletmaker system Fold, Stitch, trim .
the most productive and technologically-advanced collating and booklet making solution in the industry . . . the System 4000! .
speeds of up to 5,000 booklets and 10,000 collated sets per hour''.
.
The Duplo 10/60 Paper Collator 10 station is a high-speed suction feed vertical collator, ideal for the demands of the short run, fast turnaround print market. Compared with most suction collators on the market.
.
- Suction feed for trouble-free operation.
-Touch screen control for ease of set up.
- Air Management System to each bin delivers consistent feeding on all paper types and weights.
- Continuous operation thanks to block feeding mode.
- 120 x 148mm to 350 x 500mm paper formats.
- Handles litho and digital printed work.
- Programmable to feed alternative covers or sections.
- Hand marrying to feed precollated sets.
- Error Detection: Bin Empty.
- Double Feed.
- Mis-feed,.
- Cover Open.
- Paper Jam.
- Optical Mark Recognition.
- Downstream finisher error.
- Dimensions (LxWxH): 44" x 30" x 40".
- Weight (lbs): 300.
.
.
Trimmer.
.
Trimming Mechanism: Upper and lower shearing action.
Booklet Sizes (Min./Max.): 4.73” x 3.35” to 14’ x 10”.
Trimmed Booklet Sizes (Min./Max.):4.72” x 2.87” to 14” x 10”.
Trimming Margin: Up to 2.95” .
Cutting Thickness: Up to 50 sheets.
Speed: Up to 4,200 sets per hour*.
.
.
.
.
.
Bookletmaker.
.
CORNER/SIDE/TOP STITCHING APPLICATION.
Sheet Size (Min./Max.): 4.73” x 5.51” to 13.82” x 14.41”.
Paper Capacity: Up to 30 sheets.
Speed: Up to 4,200 sets per hour*.
Detection: Jam and misfeed.
Number of Stitcher Heads:1-4 (2 standard) Hohner heads.
Stitch Positions: Saddle, corner, side, none (fold only).
Programmable Memory Settings:8.
Automatic Functions: Stitcher heads, back jogger, side guides, .
stitch stopper, fold stopper and fold-back .
stopper positions.
.
.
.
Duplo dam 400 stacking unit .
for straight and offset stacking
| Model | Duplo-4000 Tower |
|---|---|
| Manufacturer | Duplo |
| Machine Availability | Immediately from stock |
| Machine Condition | In Stock |
| Price | On Request |
| Location | United Kingdom |
About Duplo - 4000 Tower
The Duplo 4000 Tower is a high-performance, automated perfect binding machine designed for heavy-duty use in commercial printing, bindery, and finishing operations. This machine is ideal for producing high-quality, professionally bound books, manuals, and other publications. Key features of the Duplo 4000 Tower include its high-speed binding capability, advanced automation, and precision engineering, making it an excellent choice for large-scale production environments. The machine's benefits include increased productivity, reduced labor costs, and improved finished product quality. Typical applications of the Duplo 4000 Tower include bookbinding, catalog production, and manual finishing.
Key Technical Aspects:
Dimensions and Specifications : The Duplo 4000 Tower measures 144 inches (3658 mm) in length, 48 inches (1219 mm) in width, and 72 inches (1829 mm) in height, with a weight of approximately 4,400 pounds (2,000 kg). The machine has a maximum binding capacity of 4,000 books per hour.
Paper Handling : The Duplo 4000 Tower features a high-capacity paper handling system, including a 24-inch (610 mm) wide feed tray that can hold up to 3,000 sheets of paper. The machine is equipped with advanced paper detection and correction systems to ensure accurate and efficient paper handling.
Printing Unit : Not applicable, as the Duplo 4000 Tower is a binding machine and does not have a printing unit.Ink System : Not applicable, as the Duplo 4000 Tower is a binding machine and does not use ink.
Plate Cylinder : Not applicable, as the Duplo 4000 Tower is a binding machine and does not use a plate cylinder.
