We are pleased to offer:.
Used Morgana Booklet Maker BM 2000S Year 2019.
Specification.
Air assist feeder unit.
Large LCD programmable display.
Up to 4000 sets per hour in collate mode.
Feed pre-collated sets from digital devices.
High quality ISP stitching head.
30 x 80gsm sheets, booklets up to 120 pages.
Up to 1800 sets/ per hour.
High quality front edge trimmer unit.
.
Includes:.
BM 2000S Booklet Maker.
AF602 Feeder.
FTR 2000 Trimmer.
SQF 2000 Squarefolder unit for flat spine booklets.
.
BM 2000S Booklet Maker.
Capacity: 1-25 sheets of 80gsm.
Speed: Up to 1800 sets/hour.
Sheet Size Max: 320 x 470mm / Min: 120 x 210mm.
Paper Weight Max: 300gsm / Min: 60gsm.
Stapling modes: Saddle, edge and corner stapling.
Stitching heads: 2.
Job saving: Yes, 10 jobs.
Dimensions: incl. base and belt stacker, 1135(H) x 1520 (W) x 680 (D) mm.
Weight: 161kg.
.
AF602 Feeder.
Number of Sheets: 2 x 270mm / 2700 sheets (80 gsm / 20 lb. bond).
Maximum Sheet (Width X Length): 350mm / 13.77"- 660mm / 25.98".
Minimum Sheet (Width X Length): 120mm / 4.72"- 210mm / 8.2".
Paper Weight: Max. 300gsm (76lb bond) / Min. 60gsm (14lb bond).
Productivity/Speed: Feeding Speed (Note: Speed is limited by booklet maker) Up to 15,000 Sheets/Hour.
.
FTR 2000 Trimmer.
Capacity: 30 sheets of 80 gsm (20lb. bond).
Booklet length: Max. trimming 220mm/ Min. trimming 120mm.
Booklet length: Max. by pass 235mm /Min. by pass 105mm.
Booklet width: Max. 320mm / Min. 120mm.
Speed: Up to 1800 sets/hour.
Trim length: Up to 15mm.
Dimensions: incl. base, 1100(H) x 350(W) x 595 (D) mm.
Weight: 83kg.
.
SQF 2000 Squarefolder.
Capacity: 30 sheets of 80gsm.
Booklet (width x length): Max. 320mm -228mm /Min. 120mm- 105mm.
Speed: Up to 1800 sets/hour.
Dimensions: Incl. base, 1100(H) x 350(W) x 595(D) mm.
Weight: 60kg.
Good working order.
Available immediately.
.
Read more: https://www.jerrycurtin.com/machine/en-134480/morgana-bm-2000-s-booklet-maker...
The Morgana BM 2000 S is a high-performance booklet-making machine designed for efficient production of professional-quality booklets, brochures, and catalogs. Part of the Booklet machines category, this 2019 model combines precision stitching, trimming, and folding capabilities to deliver finished booklets at speeds up to 1,800 sets per hour. Key features include an air assist feeder unit, programmable LCD display, ISP stitching head, and integrated trimming and squarefolding units. Ideal for print shops, in-plant operations, and digital printing environments, the BM 2000 S handles pre-collated sets from digital devices, supporting a wide range of paper sizes and weights while ensuring consistent, high-quality output for applications such as marketing materials, reports, and manuals.
Key Technical Aspects:
Dimensions and Specifications : The BM 2000 S booklet maker, including base and belt stacker, measures 1135(H) x 1520(W) x 680(D) mm and weighs 161 kg. It supports job saving for up to 10 presets and operates at speeds up to 1,800 sets per hour (4,000 sets per hour in collate mode). The system includes the AF602 feeder (1100H x 350W x 595D mm, 83 kg), FTR 2000 trimmer (1100H x 350W x 595D mm, 83 kg), and SQF 2000 squarefolder (1100H x 350W x 595D mm, 60 kg).
Paper Handling : The machine accommodates sheet sizes from 120 x 210 mm to 320 x 470 mm, with a paper weight range of 60–300 gsm. The AF602 feeder supports up to 2,700 sheets (80 gsm) with dimensions from 120 x 210 mm to 350 x 660 mm. The FTR 2000 trimmer handles booklets up to 320 mm wide and trims lengths from 120 mm to 220 mm (235 mm in bypass mode). The SQF 2000 squarefolder processes booklets up to 320 x 228 mm.
| Model | Morgana-BM 2000 S |
|---|---|
| Manufacturer | Morgana |
| Year | 2019 |
| Machine Availability | Immediately |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Ringwood, UK |
