Tokyo - Tokyo Pack

Key Technical Aspects:

Dimensions and Specifications : The Tokyo Pack 440 has a footprint of 4,400 mm (173 in) in length, 1,800 mm (71 in) in width, and 1,900 mm (75 in) in height. It weighs approximately 4,500 kg (9,921 lbs) and has a maximum web width of 440 mm (17.3 in).

Paper Handling : The machine features a 10-station turret unwinder with a maximum roll diameter of 1,000 mm (39.4 in) and a web tension control system. It is equipped with a servo-driven rewind unit with a maximum rewind diameter of 800 mm (31.5 in) and a rewind tension control system. The Tokyo Pack 440 has a maximum printing speed of 200 m/min (656 ft/min) and is capable of handling a wide range of substrates, from 12 μm to 300 μm in thickness.

Printing Unit : The printing unit is equipped with 8-color decks, each with a print width of 440 mm (17.3 in). The machine uses a photopolymer plate system with a plate cylinder diameter of 440 mm (17.3 in) and a repeat length of 355 mm (14 in) to 740 mm (29.1 in). The Tokyo Pack 440 features a high-precision gearless servo-drive system, ensuring accurate registration and consistent print quality at speeds of up to 200 m/min (656 ft/min).

Ink System : The machine uses a water-based flexographic ink system with a total ink capacity of 20 liters (5.3 gal). The ink system features a closed-loop ink circulation system, ensuring consistent ink viscosity and minimizing waste.

Plate Cylinder : The plate cylinder is designed for easy plate mounting and features a pneumatic clamping system. The cylinder has a diameter of 440 mm (17.3 in) and a repeat length of 355 mm (14 in) to 740 mm (29.1 in), allowing for flexible printing of various repeat lengths.
